Help CenterSpun Concrete Pole Making Machine Concrete Pole Crane
Related Products
-
Spun Concrete Pole Making MachineUS$ 10,000 - 30,000MOQ: 1 Set -
Good Price Spun Concrete Pole Making MachineUS$ 10,000 - 30,000MOQ: 1 Set
-
Good Quality With Low Price Spun Concrete Pole Making MachineUS$ 10,000 - 30,000MOQ: 1 Set
-
Prestressed Cement Concrete Poles Making Machine Hot SaleUS$ 10,000 - 30,000MOQ: 1 Set
-
Lowest Price Prestressed Concrete Poles MachineUS$ 10,000 - 30,000MOQ: 1 Set
Specifications
professional used for concrete electric pole, drain pipes making.It is advanced, safe, reliable, and easy disassembly
1:The Spun Pole/pile Spinning machinery is for concrete pole/pile
2: Long life time
3: Easy Maintainence
Our Automatical Prestressed Concrete Spun Pole/pile Production Line can make pole/pile range from 6,7,8,9,12,15,16,30m,design according to your demand
Overview |
This machine is a kind of mould equipment, which used for making a variety of different diameter and length of reinforced concrete poles and other cement products. |
Working Principle |
1. Adding the slurry into the mould, it is driven quickly and rotated in the same speed of the machine. Each component is separated and released under the centrifugal force. Usually the higher the slurry rotate speed, the better the slurry separating effect. |
Features |
1. Saving a great deal of steel, about 30~70% (employing cold drawn steel wire can save 30%~60%; employing high stress steel wire can save 40%~69%). |
No. |
Item |
Unit |
Types and forms of composition |
|||
Double Riding Wheel |
Three Riding Wheel |
|||||
1 |
Riding wheel trea d |
MM |
2000 |
2000 |
||
2 |
Riding wheel base |
MM |
800 |
800 |
||
3 |
Riding wheel external diameter |
MM |
550 |
550 |
||
4 |
Width of riding wheel |
MM |
80 |
80 |
||
5 |
The angle of center of riding wheel and wired of the center of steel mould α |
(°) |
75°-110 |
|||
6 |
Max. Length of Molding Pole |
M |
15 |
15 |
||
7 |
Diameter of molded pole |
Root apex of tapered pole |
M |
550 |
550 |
|
Equal-diameter pole |
M |
500 |
500 |
|||
8 |
Motor Power |
KM |
22 |
45 |
||
9 |
Range of speed of drive shaft |
r/min |
60-600 (continuously) |
60-600 (continuously) |
||
Technical Parameter
top end inner diameter (mm) |
Tread (mm) |
Running wheel diameter (mm) |
Length (m) |
150 |
2000 |
600 |
7-12 |
170 |
2000 |
600 |
7-12 |
190 |
2000 |
650 |
7-15 |
230 |
2000 |
650 |
6-9 |
300 equal diameter |
2000 |
600 |
6-9 |
350 equal diameter |
2000 |
650 |
6-12 |
310 |
2000 |
650-780 |
6-15 |
1. Commitment to quality and one year guarantee for main body.
2. We arrange engineer to supervise installation, make the load test, do commissioning, train of the buyer's workers.
3. Customer service 24 hours per day, 7 days per week.
4. Technique support: for any time, any way.
