Specifications

floating shrimp pellet machine/ puffed fish food machine

Floating fish feed pellet machine/fish feed pellet extruder machine

1. International advanced &diced structure, adopt cutter positioning spring and cutting forms, frequency, cut out and dice various different lengths of particles.

2. Innovative, unique design, simple structure, easy disassembly is discharged transvestite, convenient operation.

3. Screw adopts special wear-resisting, high temperature resistant materials after the first conditioning heat molding, wear resistant and long life.

4. With distinctive turbocharged punching, ensure the quality and yield of feed.

5. Reasonable combination of practical spindle bearing, ensure the security and reliability of extrusion machine.

6. The main motor adopts high-quality Y series three-phase motor, ensure the power is strong.

7. Production buoyancy particles floating on the surface of extrusion feed can not keep 12 hours, fish and poultry bubble eat easy digest, artificial to observe the appetite of fish, not: wow, won't cause feed waste water pollution.

 8. The high temperature and high pressure effectively kill salmonella typhimurium, escherichia coli, etc, to ensure that the virus harmful to health, the feed protein degeneration absorption and starch pasting, easy to fish and poultry.

Model

HX-120

HX-95

HX-75

HX-65

HX-52

Capacity --- kg/h

500-600

400-500

250-310

80-120

50-60

Pelleting Diameter--- mm

1.5—8

1.2-10

1.2-10

1-10

1-6

Motor Power--- kw

37kw

22kw

15kw

7.5-11kw

5.5-7.5

Cutting Power--- w

1100

750

750

750

750

Screw Rod Diameter-- mm

120

95

75

65

52

Weight

1000kg

700kg

300kg

250kg

180kg

Dimension

2450*1300*1300

2300*1300*1300mm

1700*1100*1200mm

1600*1100*1200mm

1500*1100*1200mm
