home wall plastering machine
Brief Introduction
1.The unique design of the dual- rail automatic lift , automatic positioning , the main rail design height of 1.96m , host design : wide 78cm x long 80cm
2.The machine is designed to squeeze plaster , plaster thickness up to 0.2 - 3cm not fall off , further strengthened the bond strength of the mortar and the wall , dense degree more than the manual more than five times , an effective solution to the artificial plaster in mortar off and hollowing phenomenon .
3.The unique design of the plaster thickness and the second plaster joints automatic retractable motor adjustment , the adjustment range between 2mm - 50mm , free to run , to achieve a degree of automation .
1.Yin and yang, the angle forming device is specifically designed based on years of experience in construction company's technical staff .
2.The professional design of automatic retractable motor adjustment control verticality and the second rail positioning to achieve the plaster , the whereabouts of the mobile location at the same time , significant savings in time and solve this problem up outside the host .
Breakthrough of the biggest challenges of the whitewashed wall machine:manufacturers of domestic and market can not solve so far for different floors of a high degree of automatic movements , and an effective solution across the room the construction of fills .
Features & Advantages
1.The volume is small, the weight is light , easy to move (automatic walking, automatic positioning, automatic adjustment of the plaster thickness , automatically adjust the plaster joints ) ,
easy to operate .
2.Positioning mode , our company developed a complete positioning system , combined with laser positioning ; the positioning is simple , fast , high precision . Really reached the whitewashed wall of the precedent of automation at home and abroad , to effectively guarantee the accuracy of wall roughness and verticality.
3.This machine equipped with operating platform, very lightweight, weighing only 20Kg.The base is provided with a universal wheel, can be very handy operation.
The main technical performance indicators
Single-phase motor |
0.65kw |
Startup mode |
Control button ( distribution box) |
Motor speed |
1440n/min |
Reducer |
Reduction ratio30 :1 |
Plastering speed |
3.5m/39s |
Plaster width |
0.3m- 0.8m |
Plastering height |
0.5- 4.5m |
Plaster efficiency |
2.56 m2/39s |
Plastering time |
39s |
A plastered area |
2.56m2/39s |
Secondary calender time |
39s |
Secondary pressure light area |
2.56m2/39s |
Flatness error |
≤3mm |
Vertical error |
≤ 3mm |
Flatness, plaster thickness , |
24v 30w |
Walking speed |
10m/ Minute |
Vertical adjustment motor |
24v 30w |
Alignment guide motor |
550W |
Walking mot |
550w |
Reducer |
30 :1 |
Lifting motor |
0.65kw |
Reducer |
30 :1 |
Console shape size |
30cm*50cm*80cm |
Console weight |
20kg |
The plaster drive motor |
650w |
Reducer |
30 :1 |
The main rail height |
176cm |
Positioning rail height |
176cm |
