wood pallet press machine | wooden pallet block making machine | wooden pallet strapping machine
| Model | Double Head | Four Head | Six Head |
| Size | 4900*660*1800 | 4900*800*1800 | 4900*940*1800 |
| Capacity | 2-3m3/24h | 4-5m3/24h | 6-8m3/24h |
| Glue water amount | 100-120kg/m3 | 100-120kg/m3 | 100-120kg/m3 |
| Density | 550-600kg/m3 | 550-600kg/m3 | 550-600kg/m3 |
| Weight | 1000kg | 1500kg | 2200kg |
| Power | 12kw | 16-18kw | 24kw |
*Wood block making machine is used to recycle the wood sawdust, shavings and other wood waste, to make blocks, feet, log for wood pallet, which can be used in packing industry and logistics. Our wood block machine is made up of Cursher, Dryer, Gluing Mixer, Hot Press Machine to cut block piece by piece.
*Wood block making machine is also an ideal machine using hot pressing principle for moulding small wood chips, wood sawdust, wood shavings or any other waste wood materials into high density, smooth, waterproof, fumigation-free and inspection-free high quality heel block.
*And the raw materal for wood block making machine is sawdust, wood shavings, waste wood, used pallet and so on. If the raw material is really big, the crusher can be used firstly.
Production Line of Wood Block Making Machine
Crushing the raw material-----Drying-----Mix the glue-----Press wood pallet block machine-----Cut the long block into small type-----Construct the block and the wood board into wood pallet
1.Using dryer to dry wood chips or shavings.
2.Using glue mixer to mix the wood chips or shavings with glue.
3.The wood block is widely used in packing industry and logistics.
4.Using wood block machine to mould the mixed wood sawdust and glue into long blocks.
Raw Materials Requirements for Wood Block Machine
1.Glue: Urea formaldehy glue.
2.The materials size is about 5cm.
3.The materials moisture content within 10%-12%.
4.If the materials can not meet above request, you need crusher and dryer machine.
5.The materials can be wood sawdust, wood chips, wood shavings and other small waste wood materials.
Disposition of Wood Block Making Machine
*Equipment Disposition: Generally four hot presses are a production line, with providing the gluing machine, grinder each. (dryer, gluing machine, crusher and so on supporting facility customer purchase in addition).
*Personnel Disposition: Production personnels are 4-5 person per shift. And raw material sort (screening), drying, spreads 2-3 people. With 2 people looking after the machines.
*Production Cycle: After confirmation order form and advanced payment, 40 super craftsmen ship factory delivery.
*Equipment investment recoupment period for 10-12 month. Our factory is responsible for the technical training, and provides the consumption the post-sale service.
Features of Wood Block Making Machine
1.Strong bearing capacity, no deformation and can be reused.
Pallets can be used in export package, free fumigation, and free quarantine.
3.Insects prevention, and protection against termites and do not easy to burn.
4.This wood sawdust block press machine uses hydraulic transmission, horizontal continuous out bags, speed high yield.
5.The sawdust block press machine is mainly applicable for sawdust, cotton seeds, shell husk compression moulding material, facilitate their storage, transportation cost.
6.Broken material vias the massive objects, compressed into directly handling, no bag.The rear can spread by us.
FINISHED PRODUCT
