Specifications
high qualiy soil cultivating machine with best selling1.Direct-coupling Diesel Tiller
2.Higher Efficient
high qualiy soil cultivating machine with best selling
This kind of rotary cultivator has many advantages such as new style, stable structure, steady performance and reliable quality, which can matched with big horsepower and high ground clearance tractors well. So it can apply to rotary tillage in large area of field after returning straw.
The high-box rotary cultivator is desired products for users to equip with big horsepower tractor, because it can meet the high ground clearance and small oblique angle of gimbal well for big size tractor. In addition, it avoids blocking up weeds after smashing straw in the corn field owing to its high frame and hood to ground.
Its box is made of high strength nodular cast iron. This machine has higher rigidity than common rotary cultivator on the formation such as suspension arm and bracket, side plate, cutter shaft, hood as well as drag plate etc. After selecting optional pressurized roller or pressurized embossing roller, it can be suitable for agricultural requirement in various regions.
Main specifications
Model |
FR-200 |
FR230 |
FR-250 |
FR-280 |
|
Matched power Kw (HP) |
40.4-51.4 (55-70HP) |
47.8-58.8 (65-80HP) |
58.8-73.5 (80-100HP) |
73.5-80.6 (100-110HP) |
Working width (m) |
2.00 |
2.30 |
2.50 |
2.80 |
Working depth(cm) |
Dry field: 8-16, Paddy field: 8-18 |
|||
Type of blade |
IT245 |
|||
Qty. of blade for tap side (pcs) |
29 |
31 |
33 |
35 |
Diameter of cutter shaft (mm) |
76 |
83 |
83 |
83 |
PTO speed (R/M) |
540 |
720 |
760-780 |
790 |
Gear qty. ratio of bevel gear |
15:24/21:33 |
17:37/19:35 |
17:37 |
17:40 |
Blade shaft speed (R/M) |
231/235 |
226/267 |
239-245 |
230 |
Productivity (ha/h) |
0.28-0.98 |
0.32-1.13 |
0.35-1.22 |
0.38-1.33 |
|
Overall dimensions (mm) (L×W×H) |
1020×2345×1302 |
1020×2586×1302 |
1020×2776×1302 |
920×1782×1302 |
Weight (kg) |
450 |
465 |
490 |
560 |
