Home > Industrial Equipment & Components > Ventilation Equipment > Blowers > Vacuum Pump

Vacuum Pump

Vacuum Pump thumbnail-1
Vacuum Pump photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Hetian
Model Number:
HDSR-V-150
Contact Supplier Request Quote Chat Now
Qingdao Hetian Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Hetian
Model Number HDSR-V-150
Application Air Blower
Type Roots Blower
Pressure Medium Pressure
Power Source Electric Blower
Rated Power 4-30kw
Rated Voltage 380V,400V,415V

Specifications

1)vacuum pump
2)fast start, less power consumption
3)high efficiency
4)50HZ, 60HZ

vacuum pump

Features: fast start, less power consumption, low operation and maintenance costs, pumping speed, high efficiency, not sensitive to the small amount of water vapor contained in the pumped gas and dust. Have a greater pumping rate that can quickly rule out the sudden release of gas. The pressure range is connected in series between the oil seal mechanical vacuum pump and spread pump to increase the outlet volume of the intermediate pressure range. At this point it is called mechanical booster pump.

Application: The model is widely used in vacuum packaging, vacuum metallurgy, Vacuum distillation, Vacuum concentration and vacuum drying, smelting, off-gassing, rolling as well as chemical, food, and medicine industries, etc.



Model: HDSR-V-150
Capacity scope: 11.0-26.50m3/min
Pressure scope: -100mmHg--300mmHg
Discharge dia.: 150mm
Cooling type: Air Current
Drive type: belt&pully, direct coupline
Matched motor power: 4-30kw
Usable voltage: 380V,400V,415V
Frequency: 50HZ, 60HZ
Weight: 470-490kg
Dimension: 1270×860×1680mm
Package Dimension: 1400×900×660mm






 We can offer you the following types more, please take your choice.


HDSR-V-50
HDSR-V-65
HDSR-V-80
HDSR-V-100
HDSR-V-125
HDSR-V-150
HDSR-V-175
HDSR-V-200
HDSR-V-250
HDSR-V-300

vacuum pump
