20Watt fiber laser marking machine price fiber laser marker Price
INTRODUCTION:
With the first-class marking technology, it can work on sculptured surface without defocus. Configured with specialized 3D vibrating mirror, the 3D dynamic laser marking can control the software and hardware, and the laser beam can mark on arbitrary 3D sculptured surface.
SPECIFICATION :
Model No |
LX-A4 laser engraving machine |
||
Laser Parameter |
Laser Source |
laser engraving machine |
|
Wavelength |
1064nm |
||
Output Power |
30W |
||
M2Laser Beam Quality M2 |
<1.2 |
||
Pulse Repeatable Frequency |
10kHz~200kHz |
||
Cooling Method |
Air cooling |
||
Processing Parameter |
|||
Processing Range |
140×140×60mm |
160×160×70mm |
|
Lens Focal Length |
200mm |
254mm |
|
Max Speed in X-Y Axis |
6m/s |
||
Max Speed in Z Axis |
4m/s @45° |
||
Min Linear Width |
150μm |
||
Positioning Accuracy |
25μm |
||
Contraposition Accuracy |
20μm |
||
Whole Machine Parameter |
Operating Ambient Temperature |
18~28℃ |
|
Power Demand |
Single phase AC220V 10A |
Three phase AC380V 10A |
|
Overall Power Consumption |
3KW |
||
Dimension |
Mainframe 1200×1000×1610mm |
||
width×length×height |
Smoke Dust Exhaust Ventilator 680×650×1550mm |
||
Weight |
Mainframe 350kg |
||
Smoke Dust Exhaust Ventilator 100kg | |||
FEATURES:
1.High precision of 3D positioning technology, high-speed focusing and scanning system, short pulse, high-peak power and HPRF (High Pulse Repetition Frequency);
2.With friendly operation interface, it is suit for many file formats, such as dxf, plt, cnc, step, iges, etc;
3.High electro-optic conversion efficiency, long life and easy maintenance;
4.Fast marking speed and high processing efficiency.
3d uv laser marking machine engraving machine for glass APPLICATION:
It’s suitable for all kinds of metals and nonmetals laser marking on 3D surface. It’s widely used in mobile manufacture, cubic circuits, medical equipments, moulds, 3C electronics, auto parts, electronic communication, etc.
Linxuan laser develops 3D equipments to complete the anodizing treatment at one time for height difference beyond 10mm, instead of replacing the fixture and processing repeatedly.
PROCESSING SAMPLE SHOW:
PACKAGE AND SHIPPING:
1.Durable wooden case or as per required.
2.The delivery lead time would be 5-7 working days after recieving the payment.
3.As for the wholsalers/distributors, we could send the cargo by air, by sea or by railways via reliable forwarder.
