Dalian Jialin Machine Manufacture Co., Ltd. is a professional manufacturer specialized in developing, designing, producing and installing auto conveyors (standard or nonstandard), packing machines and medical apparatus, etc.
Located in Dalian City, our company covers an area of 5,300 square meters with a building area of 5,000 square meters. Total assets over USD2,500,000. There are 120 employees, including 27 professional technicians.
Being ISO9001:2000 certified, we have import and export right, and also have manufacture license of medical apparatus. We keep supplying machines worldwide reguarly and had won sound reputation among our customers. We try our best to supply the optimal conveyors for you all the time!
Process Description:
Climbing belt conveyor→ turning belt conveyor → high speed carton erector → Rolling code machine→ pressing machine → weight checker → packing machine →carton sealer → robot palletizer → Wrapping machine
1) Climbing belt conveyor
Climbing conveyor
also call climbing belt conveyor, belt conveyors with a simple and universal structure, reliable operation, easy maintenance, etc., having a large angle (90 degrees vertical) transmission, compact, small footprint, etc., so it is ideal for large angle (or vertical) transport. Climbing conveyor is widely used in all types of transportation goods. Through years of unremitting efforts, climbing conveyor has safe, stable and reliable.
Climbing conveyor Application:
(1) climbing conveyor for general use of bulk materials continuous conveyor equipment, but uses a conveyor belt having corrugated wall and transverse bulkheads. Therefore, especially for large inclination and 90 ° vertical transport.
(2) climbing conveyor can be used in coal, chemical, metallurgy, electric power, light industry, food, ports and other industries, the working environment temperature -15 ℃ ~ + 40 ℃ in the range of transport bulk specific gravity of 0.5-4.2t / m3 of various bulk materials.
(3) there are special requirements for the delivery of materials, such as: high temperature, with materials acids, alkalis, oils or organic solvents and other ingredients, and requires the use of special conveyor belt.
(4) as the transmission angle 0 ° ~ 90 ° range.
Features:
1, the transmission capacity, simple structure;
2, easy maintenance, the parts standardization;
3, according to transportation technology requirements, single conveyor can also be composed of multiple components;
4, with other transportation equipment horizontal or inclined transportation system to meet the different types of operating line arrangement needs.
5,rubber conveyor belt line, canvas, PVC, PU, PVK other materials, except for the transport of ordinary materials, but also meet the oil, corrosion-resistant, anti-static materials have special requirements of transportation.
6,the belt conveyor is dedicated food grade conveyor belt to meet the food, pharmaceutical, household chemical and other industries.
7, smooth transportation, raw materials and the conveyor no relative motion, can avoid transporting material damage.
8,less noise compared with other conveyor suitable for relatively quiet working environment requires occasions.
2) Turning belt conveyor
Turning over belt conveyor belt belonging to one of the drivers go through a tapered roller drive to install a special leather steering turn bring realization belt rail movement. And such that the delivery of goods smooth transition turning .
belt conveyor 30 degrees belt curves, belt curves 45 degrees, 90 degrees belt curves, 180-degree turn belt machine, can meet a variety of turning delivery process requirements. Conveyor belt curves have PVC, PU and other materials, except for the transport of ordinary materials, but also meet the oil, corrosion-resistant, anti-static materials have special requirements of transportation. Using a dedicated food grade conveyor belt to meet the food, pharmaceutical, household chemical and other industries. Smooth transportation between the material and the conveyor belt is no relative motion, can avoid transporting material damage. Less noise, suitable work environment requires relatively quiet compared to other conveyor occasion. Simple structure, easy maintenance; less energy consumption, low cost.
Scope:
Widely used in food, beverage, electronics, tobacco and other industries, we can use smaller diameter rollers make it easier to connect the corner, the perfect solution to the problem of transition. The device is suitable for a variety of assembly-line manufacturers, small and medium sized goods transportation logistics, power system frequency control system, stable, secure, reliable, easy to operate.
3) High-speed carton sealer.
1.Description:
By JOLINPACK professional design, and awarded the patent of High speed carton erector JTK - 03 h series, used the CAM continuous system, machine precision, stability and durability.
Carton forming part adopts no period of variable speed control, the speed can be adjust. Carton storage part adopts horizontal structure, can complement the cartons.
Can choose the tape or hot melt glue forms.
Can also be customized according to customer's requirements.
a.It mainly suits for forming the cartons. It can be singly used and combined with packaging line.
b.It is widely used in the Beverage, Chemical, Commodity, Food, Machinery & Medical etc.
c.It seals bottom of the carton with adhesive tape at one time.
d.The JTK-03H series is simple to operate and adjust.
e.Case size changes are made without tools by the operator in less than two minutes with easy to use hand wheel settings.
4) rolling code machine
Automatic printing machine
Spray printing ability
Single nozzle,
· G - nozzle (71 dpi) spray print resolution:
Can spray print up four lines
Spray printing speed: up to 4.4 m/s
The font height: 5 lattice to 24 bitmap
Information, height: 1.8 mm to 8.7 mm
Bar code and qr code
Many languages can choose: Chinese, Arabic, Cyrillic, Greek, Latin, Japanese, Hebrew, Korean, etc
Graphics editor: can directly edit graphics on the keyboard/interface
Operating functions
Large capacity information database, can store up to 100 messages
, internationalization operating interface (31 kinds of optional language)
Wysiwyg backlit blue, large screen display
The built-in help menu: operating hints and fault diagnosis
, can be directly edit graphics on the interface
Supported PCMCIA card and read of the Compact flash card
IC60 ink loop
Chalk line speed closed-loop control ensure the quality of jet printing
According to the spray printing speed/spray distance automatically choose the font
A variety of printing ink to choose from: quick dry ink base ink with ethanol
Two, airtight oil ink cartridge (0.8 liters)
With photoelectric sensor, alarm lamp and accessories such as synchronous encoder rapid connect and disconnect
Product features
Weight: 19.5 kg
3 meters long, flexible pipes
Stainless steel casing,
5) Pressing Machine
6) weight checker
Product description
mainly used in automatic assembly line and logistics delivery system on automatic weight detection, upper and lower limit or weight classification, widely used in pharmaceutical, food, toys, hardware, chemical and other industries online testing. In addition, it can directly replace manual weighing, in order to improve the efficiency of production, as well as the consistency and reliability.
2. Equipment data sheet
Machine Model |
JTJZ-20 |
||
weight checker: |
<25kg |
||
checking accuracy |
±10g |
||
selecting speed |
15m/min |
||
selecting mode |
automatic alarm + pneumatic selection |
||
product preset mode |
10type |
||
machine weight |
160kg |
||
conveyor width |
500mm |
||
power supply |
1ph 220v 50Hz |
||
product size |
L200-600(W00-500)H100-500mm |
||
3. Competitive Advantage:
Automatic selection, automatic selection, convenient and quick;
Adjustable speed - high precision detection, transmission speed can be adjusted;
Parameter setting - the upper and lower limits of the weight parameters of arbitrary setting;
Frequency conversion and speed regulation - frequency conversion speed regulation mode, which is convenient for speed adjustment;
Data storage - strong data statistics, daily test data;
Data call - a set of data memory, calling functions, easy to operate;
Data record - OK number, the number of the number, the number of overweight, respectively;
Fault diagnosis: self fault diagnosis and prompt function, convenient maintenance;
Storage of multiple groups - the set of 100 sets of parameters to save;
Handling mode - non - qualified product alarm / stop, remove optional
7) packing machine
8) carton sealer
JTC-05 is a semi auto flaps folding and side belts driven carton sealer ,it can be applied in cases with different sizes and different sealing manners,
a.It mainly suits for sealing the carton. It can be singly used and combined with packaging line.
b.It is widely used in the Beverage, Chemical, Commodity, Food, Machinery & Medical etc.
c.It seals both top and bottom of the carton with adhesive tape at one time.
d.The JTC-05 is simple to operate and adjust.
e.Case size changes are made without tools by the operator in less than one minute with easy to use hand wheel settings
2. Equipment data sheet
Machine Model |
JTC-05 |
Carton size |
(L)150mm~infinity(w)150~500(H)120~500mm |
Table height |
Min.600,max.800mm |
Capacity |
400~900ctns/h |
Machine size |
L770mm(W)735mm(H)1,200-1600mm |
Machine surface |
Plastic spraying processing |
Power |
Taiwan brand 110/220V,single phase,50/60Hz or specified by clients |
Tape width |
48,60,75mm(choose one type) |
Machine net weight |
Approx.180kg |
Packing material |
Corrugated paper |
pneumatic |
5kg/cm² |
Competitive Advantage:
Machine Features:
1:This machine is designed for simple, economical and durable, safe, low failure rate based.
2:According to carton width and height manually adjust the machine, for the same period of time only seal same size carton.
3:Carton into the 90degree forward body, push the box from the corner into the side sealing machine, automatic carton sealing both the upper and lower side corners, smooth
4:Sealing beautiful, fast, labor-saving, high efficiency
5:Equipped with blade guards to prevent accidental stabbed during the operation
9) Robot palletizer
1. Description:
Palletizing robot is a kind of packaging, transportation and orderly placed industrial robots of various shapes cartons, bags, cans, beer boxes, bottles and other product, is widely used for food, fertilizer, hardware, beverage, electronics, steel and other industries.
2. Equipment data sheet
Machine Model |
JTRB-120 |
||
power supply |
380V 50/60Hz 5.8KW |
||
suitable pallet size |
L1200*W1200 |
||
PALLETIZE WEIGHT |
120KG |
||
action weight |
4 axis |
||
capacity |
1600 C/hr |
||
Gripping device |
clamp plate,finger,sucking plate and others |
||
Tape width |
48,60,75mm(choose one type) |
||
Machine net weight |
Approx.850kg |
||
3. Competitive Advantage:
1.Simple structure, less components. Therefore, the failure rate of the components, the performance is reliable, the maintenance is simple, the need to spare parts and components.
2.It covers an area of less. Is conducive to the layout of the production line in the customer plant, and can set aside a large warehouse area. Palletizing robot can be installed in a narrow space, can be effectively used.
3.Applicability is strong. When the size of the customer products, size, shape and size of the tray to change the size of the only need to do a little change on the touch screen, will not affect the normal production of customers. The stacking machine mechanical changes quite troublesome or even can not be achieved.
4.The low energy consumption. Stacking machine mechanical power is usually at about 26KW, and the power of the palletizing robot is about 5KW. Greatly reduce the customer's operating costs.
5.All control operation can be in control cabinet on the screen, the operation is very simple.
6.The only catch the starting point and put the point positioning, the teaching method is simple and easy to understand.
10) Wrapping machine
1. Description:
strech wrapping machine JT-2000A applied to the pallet and pallet packaging, the winding method of various regular or irregular goods packaging, using tensile membrane retraction and self-adhesive will goods and tray bound into a whole, play a fixed role, because goods does not occur scattered packet and collapse phenomenon, of goods but also to dust-proof, moisture-proof, anti damage effect. Especially suitable for a large number of fast transportation or storage, packing cartons, bottles or bulky goods. At the same time reduce the labor intensity, improve the work efficiency, is the ideal equipment for modern enterprise product packaging.
The bottom of the supporting roller conveyor makes the whole production process can be automatically connected to the use of the production line.
2. Equipment data sheet
Machine Model |
JT-2000A |
||
max. package height |
2100mm(including pallet height) |
||
Table height |
600mm |
||
turntable load capacity |
2000kg |
||
turntable speed |
0~13 r/min(adjustable) |
||
turntable diameter |
Diameter 2000mm |
||
air supply |
5-6 kg/cm² |
||
film size |
ID:76,OD:max 250mm |
||
turntable |
1HP |
||
machine weight |
950kgs(contain wooden box) |
||
