Home > Packaging & Printing > Packing Machinery > Filling Machine > SD Automatic Brake Oil Filling Machine

SD Automatic Brake Oil Filling Machine

SD Automatic Brake Oil Filling Machine photo-1
US$ 8,001 - 20,001 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food
Packaging Type:
Bottles, Cans
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food
Packaging Type Bottles, Cans
Packaging Material Glass, Metal, Plastic
Automatic Grade Automatic
Driven Type Pneumatic
Voltage customized
Power 1.5kw
Place of Origin Shanghai, China
Brand Name shouda
Model Number SD-GZJ-J
Dimension(L*W*H) 1600*800*1800MM
Weight 450KG
Certification CE, BV, ISO9001
After-sales Service Provided Engineers available to service machinery overseas

SD Automatic brake oil filling machine

  SD automatic brake oil filling machine



SD automatic brake oil filling machine





Adopts Piston pump with rotary valve

Filling nozzles with drip-proof

Conveyor with photo sensor

Machine cabinet

PLC and Human-computer touch screen. Etc  no bottle, no filling

This machine is customized, that means it can be 4 filling nozzles/ 6 filling nozzles/ 8 filling nozzles/ 12filling nozzles etc, according to the capacity customers need.

Using the rotating type pump and  measuring the weight by Quantitative cylinder, filling quality is very accurate.







program

  fruit jam filler



Filling head



 4, 6, 8 etc(based on the capacity)



Filling volume



30-100ml, 50-300ml, 100-500ml, 300-1000ml etc(customized)



Filling speed

2000-3000(based on 6 nozzles)



Filling precision

≤±0.5%



Power supply

380V,220V 50-60HZ



power

≤1.5kw



Air pressure

0.6-0.8MPa



Net weight

450kg



dimension(mm)

1600*800*1800
