Film Faced Plywood

Products

China Origin ‘D-Crown brand’ Poplar Plywood with Harwood Veneer Face and Back, Type II, MR Glue, Both sides not sanded

(UT + UTVC + Regular Back(Both not sanded))

Checks

Adhesion

Type I : 4hr in boiling water & 20hrs drying at 60°C x 2times

Type II : 2hrs in boiling water & 3hrs drying at 60°C

Moisture Contents

Less than 15%

Species

Okume Face & Back with Poplar Core Veneer

Density

Color

Red or White, Both sides

F/B Veneer Thickness

0.20mm up for face

Core Veneer Thickness

Thickness Allowance

3.6-5.5mm –0.3mm

9mm & Up –0.5mm

Allowance

in Length/Width

-0 /+1.6mm

Diagonal Allowance

Max. 3.0mm

Warp

0.1%

Natural Characteristics

Standard (IHPA-Utility) Face/Back

Burls, Sound

Yes, Smooth / Yes

Pin Knots

Yes

Knots

Yes

Sound Live Knots

Yes

Soft Dead Knots

Puttied / Yes

Knotholes

25.4mm max. diam. Puttied / 19mm max. diam.

Color Variation

Yes

Stain/Mineral Streaks

Yes

Dry Pitch & Bark Pockets

Puttied / Yes

Worm Holes, Pine Holes, and Worm Tracks

Puttied / 1.6mm max. diam. Not clustered at edges and ends

Vine Marks

Sanded, Smooth / Yes

Cross Break

Hairline / Yes

Doze

Firm, Puttied / Yes

Manufacturing Characteristics

Small boat or small symmetrical patches, open bark pockets, bark, wet pitch, grease/oil or colored chalk, Mechanical defects and pressmarks, if not serious, allowed in face grades. Not serious corrugated core stuck allowed. Partly inconspicuously Wrinkled and delaminated face and veneers allowed.

Joints

1 / Yes

Split-Filled or Puttied

Yes / 9.5mm x 508mm max.

Fill or Putty Smears

Yes, Smooth / sanded or scarped smooth

Rough Cut/ Ruptured Grain

Yes

Shims

Yes

Knife Marks

Sanded, Smooth / Yes

Tape/ Glue Residue

Sanded, Smooth / Yes

Edge color  smear

No

Sanding

Both Sides Smooth, Only blending or

Inconspicuous streaks or chatter

Marks permitted

Patches on back face

Not limited, May be roughly done

Core Veneers

Voids

Yes

End Splits

Yes, Not visible on face

Laps

Yes, visibly, touchable.

Uneven Core Thickness

Allowed

Number of Components

Not specified

Width of Core Components

Min.152mm, machine spliced

Packing

Vinyl Wrapping

Cover boards

Top & Bottom min. 3mm, Side min 3.0mm rigid boards

Metal Band

3/4”x 0.032gauge 4 x 3 times

Cardboard Sleeve at corners

4 corners

Runner

76mm square, Grooved to receive metal band

Logo printed on panels

blue Color, Each corner of back face

Logo paper on crates

D-Crown brand and made in china on both sides

Sheets per crate

9mm - 70 sheets

12mm - 50 sheets

15mm - 40 sheets

18mm - 35 sheets
