Brand Name WG





WG-3000D1 PLUS Ultrasonic Diagnostic Equipment

Features:

  • 10.4 inch SVGA high resolution non-interlaced monitor
  • Multi-frequency probes
  • Real-time zooming
  • 256-frame cineloop
  • 8 images permanent image storage
  • USB port
  • Multi-segment TGC adjustment





Imaging Processing:

  • Part zoom in real time, gray curve control, STC curve, edge enhancement, dynamic range, frame correlation, 256 gray scale, image reverse function
  • Pre-processing: multi-segments TGC adjustment, frame correlation, image direction
  • Post-processing: left/right, up/down, positive/negative
  • Zoom: magnification (4 steps)
  • Cine loop: 256 frames



Software Functions:

  • General measurement: distance, circumference, oval, trace, volume
  • Obstetric measurement soft: GS, CRL, BPD, AC, HC, FL, AFI, EDD, and calculating fetus weight, pregnancy week, fetal physiological rating according to the previous measurements

Peripheral Ports:

  • SVGA
  • USB port
  • VGA port
  • PAL-D video output

Specification:

Image mode



B, B/B, B/M, M,4B

Scanning mode

Convex and linear array

Multi-frequency probe

2.5~8.5 MHz

Image magnification

×1.0, ×1.2, ×1.5, ×2.0

Electronic focus

Acoustic lens focus, single focus and multiple focus

Max display depth

220mm



Depth enhancement/pan function

Yes

Local zoom

Yes

Frame correlation function

Yes

Adjustment total gain and dynamic range

Yes

Gray Scale

256

Display

10.4 inch SVGA high resolution non-interlaced monitor

Gains

0~99 dB digital adjustable

Probe connectors

2 (standard)

Storage

8 images permanent image storage

USB port

for image transferring to PC

Scanning frequency

2.5~8.5 MHz (depends on probes)

Image reverse

Left/right, up/down, positive/negative

Comment

Time, date, week, doctor name, patient ID, age, sex, transducer type, transducer frequency, gray scale, focus, average value

Body marks

35

Power supply

AC 110V, 60Hz; AC220,50 Hz



Power consumption

≤100VA

Dimensions

490x380x420mm (LxHxM)

Net weight

approx. 9.5k, g

Standard Configuration:



  • Main unit
  • 10.4 inch non-interlaced monitor
  • 256-frame cine loop
  • 8 images permanent storage
  • Two probe connectors
  • USB port
  • 3.5MHz electronic convex probe (2.5/5.0MHz)



Optional:

  •  Electronic transvaginal probe (5.0/7.5MHz)
  •  Electronic high-frequency linear probe (6.5/8.5MHz)
  • Trolley
  • Thermal printer
