Shcwing Putzmeister Concrete Pump dn125 rubber hose 2"--6" Wire braided rubber hose
Product advantage
- Our hoses be able to use 20,000 cubic meter compared with normal quality of 12,000-15,000 cubic meters in china
- integrated hose end and inner wall hardened, prolong working life
- 2 plies of steel wire reinforcement ensure the working pressure
- Hose ends can be galvanized
1. Data of concrete rubber hose (Steel):
Spec. |
Inner diameter (mm) |
Wall thickness tolerance (mm) |
Outer diameter (mm) |
Working pressure (bar) |
Bursting pressure(bar) |
Bend radius (mm) |
Weight(kg/m) |
2" |
50 |
9±0.75 |
68±1.5 |
85 |
240 |
200 |
2.6 |
2.5" |
64 |
10±0.75 |
85±1.5 |
85 |
240 |
250 |
4.3 |
3" |
76.2 |
12.9±1 |
102±1.5 |
85 |
240 |
270 |
6.1 |
3.5" |
89 |
13.5±1 |
116±1.5 |
85 |
240 |
290 |
8 |
4" |
101.6 |
14.2±1 |
130±1.75 |
85 |
240 |
300 |
9 |
4.5" |
115 |
14±1 |
143±2 |
85 |
240 |
320 |
10.2 |
5" |
127 |
16±1 |
158±2 |
85 |
240 |
360 |
12.5 |
Heavy Duty Flexible Concrete Pump Rubber Hose Application: handles cement, stone, sand and other abrasive materials in drilling, cementing service a wide range service in construction industry, mining and tunneling.
Characteristics: high tensile; wear, weather, ozone and aging resistance
Working pressure:85bar
Temperature range: -30− +80°C.
Safety factor: 1:3
Technical parameters:
Hose lining: NR, SBR, BR blend
Reinforcement layer: tire cord with helix wire
Cover rubber layer: SBR
