Stainless Steel Storage Wine Tanks
US$ 2,550 - 2,700
MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Liaoning, China
Brand Name:
Weron
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SS304 550gallon Customized Wine MakerUS$ 2,550 - 2,700MOQ: 1 Piece -
Grape Wine Fermenting TanksUS$ 2,550 - 2,700MOQ: 1 Piece
-
Fermenting Tank 550gallonUS$ 2,550 - 2,700MOQ: 1 Piece
-
Square IBC Tank With Cooling/Heating JacketUS$ 2,550 - 2,700MOQ: 1 Piece
-
Square Stainless Steel Hot Cold Storage Container for Beverage and WineUS$ 2,550 - 2,700MOQ: 1 Piece
Condition
New
Place of Origin
Liaoning, China
Brand Name
Weron
Model Number
Weron-winetote
Processing Types
Alcohol
Voltage
220V
Dimension(L*W*H)
1229*1160*2010mm
Weight
289kg
Certification
ISO9001
Warranty
1 Year
After-sales Service Provided
Overseas third-party support available
Stainless Steel Storage Wine Tanks
Product Description
ODM and OEM are welcome!
We can produce different kinds of tanks as your need !
Welcom to your inquiry.
wine fermenter tank
| Specifications | |||
| Liter | Gallon | ||
| Capacity | 2082 | 550 | |
| Material | Tank | Stainless Steel 304 | |
| Seal Gasket | Silicone Rubber | ||
| MM | INCH | ||
| External Dimention | Length | 1229 | 48.4 |
| Width | 1160 | 45.7 | |
| Height | 2010 | 79.1 | |
| Tank Dimention | Length | 1219 | 48.0 |
| Width | 1000 | 39.4 | |
| Height | 1500 | 59.1 | |
| Top Manway Dimention | φ572 | 22.5 | |
| Square Side Door Dimention | Length | 600 | 23.6 |
| Width | 400 | 15.7 | |
| Inlet on Top Lid | 50.8 | 2.0 | |
| Discharge Hole Diameter | 5.08 | 2.0 | |
| Cooling jacket inlet and outlet diameter | 12.7 | 0.5 | |
| Sampling Valve Hole Diameter | 12.7 | 0.5 | |
| temperature probe pocket | 12.7 | 0.5 | |
| Outlet Hole Diameter | 38.1 | 1.5 | |
| MM | Gauge | ||
| Tank Wall thickness | 3 | 11 | |
| Cooling jacket Wall thickness | 2 | 14 | |
| KG | LBS | ||
| Max. Gross Weight | 2369 | 5223 | |
| Tare Mass | 289 | 637 | |
| Max. Payload | 2080 | 4586 | |
| Stacking | 2 high full, no stacking during transportation | ||
| Features | |||
| This IBC tank is wonderful choice for fermenting red and white wine. It's also great for transporting and storage | |||
| beverage and wine | |||
| •Tank size is available from 500L to 3000L | |||
| •22.5" Top manway with 2" clamping inlet, silicone gasket, lock by clamping ring | |||
| • Hinged side door allows man going in tank to clean, easy operation | |||
| •Handle by crane or forklift | |||
| •Three way forklift entry | |||
| •Internal welds are polished, external surface is 2B finish(pickling and passivation) | |||
Similar goods
As a professional steel IBC tank manufacturer,we have many types.There must be a one for you.
FAQ
Why are you so much cheaper than your competitors?
Seriously, we are asked this question all the time. The answer: we are industry and trading company and have our own factory.We sell direct to the customer. No distributors. No middlemen. Also, we keep overheads down -- no marble foyers, no fancypants administrative assistants, no sales reps in flash cars with nothing to do. We price the products accordingly
Can you make up a bench to a specific size?
Yes, we welcome ODM and OEM require.We have our own design department.
