Ring die stainless steel straw hay pellets machine
- 600 Set / Sets per Month
- Qingdao/Shanghai
- T/T Credit Card
- BEFZ Household Kitchen Scale High Precision Mini Digital Balance 0.01g digital pocket scale Capacity 500g/0.01g Pocket Scale
- 2014 New arrival western ladies Rivet new fashion belt with flower leather pattern buckle Wholesale /Retail sell
- Dung cleaning machine
- mini rice mill
- stainless steel seeds roaster
- incense stick making machine
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | LYINE |
Model Number: | LYML250 | Voltage: | 380V, According to your requirement | Power(W): | 15KW |
Dimension(L*W*H): | 1420*1200*1400 | Weight: | 1T | Certification: | ISO |
Warranty: | 1 year | After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
straw pellets machine1:make pellet from different waste materials
2.stainless steel
3.capacity from 0.2 ton to 30 ton/H
Introduction of straw pellets machine :
1.straw pellets machine is used for processing pellet with different
diameter and length from virous wood and other waste materials .
2.straw pellets machine has widely applicable scope.
It can process different materials like wood chips,sawdust,straw,pasture,palm leaf ,wood waste,
branch,palm tree,sugarcane residue,sawdust,medical slag,hay,discarded edible fungus bags,
bean stalk,wheat stalk,corn stalk,cotton stalks,sunflower stalks,mustard stalk,rice stalks,
coffee husk,cotton shell,peanut shell,rice shell,coconut shell,poultry's waste,tea waste,tea waste,
forestry wastes,forestry wastes,wood chips and many other organic waste resources.
3.straw pellets machine has perfect working theory:
the raw materials are delivered into the Pellet Machine through a conveyor and then conveyed
into a rotating ring die by a feeder. finely pulverized material will be pressed into ring die through two rotating press rollers. The resulting pressure compresses the material and extrudes it
through the holes in the die. The pellet will be out directly.
Features of straw pellets machine :
1. Adopt high-precision gear driven , advanced flexible coupling, for high productive efficiency .
2. Main driving adopt imported bearing,Siemens Motor.
3. Frequency converter control feeder flow, full stainless steel feeder, cover and chute .
4. Different capacity : capacities from 0.2 ton per hour to 30 ton per hour or even more.
5. Full stainless steel. both paddle and shaft are made of stainless steel.
6.Non-dust workshop,Siemens motor,matched with auto cooling and oil adding system
Technical Parameters of straw pellets machine :
Model | Main motor power (KW) | Capacity (t/h) | Conditioner power (KW) | Pellet size | weight (T) | Dimension (mm) | Die Dia |
LYML250 | 15 | 0.2-0.3 | 2.2 | Φ6,Φ8, Φ10,Φ12
| 1 | 1420*1200*1400 | Φ250mm |
LYML320 | 37 | 0.3-0.6 | 2.2 | 2.5 | 2200*1000*1500 | Φ320mm | |
LYML350 | 55 | 0.5-0.8 | 2.2 | 3.5 | 2500*1100*1600 | Φ350mm | |
LYML420 | 90/110 | 1.0-1.2 | 5.5 | 4 | 2800*1150*1730 | Φ420mm | |
LYML508 | 132/160 | 2.0-3.0 | 5.5 | 4.5 | 3000*1260*1860 | Φ508mm |
Complete straw pellets machine line contain:
Crusher,Dryer,Pelletizing equipment,cooling machine, Pellet packing machine.
More information,please contact us.
