dryer features of techonlogy
(1)Drying Tray
1Design pressure: usually 0.4MPa, the maximum can be 1.6MPa
2Max. working pressure: usually≤0.4MPa, the maximum can be 1.6MPa
3Heating medium: steam, hot water, conduct oil, to heat drying tray in hot water when its temperature is 100, to heat drying tray with ≤0.4MPa saturated water vapor or superheated steam when its temperature is 100~150, to heat it with conduct oil when its temperature is 150~320, while the temperature is >320, it can use electricity, conduct oil and molten salt to heat it
(2)Material transportation system
1.Rotate speed of main shaft: 1~10/minute, electromagnetism or stepless speed regulation of frequency conversion
2.Rabble: each drying tray has 2~8 rabbles fixed in main shaft
3.Shovel blade: jointed in rabble, to move up and down with the surface of the drying tray to keep contact, having many forms
4.Grinding and rolling: to make grinding and rolling in place to agglomerative and crushing material that can enhance heat-transfer and drying process
(3)Shell
It has normal pressure, airtight and vacuum three types
1.Normal pressure type: cylinder or octahedron, having whole and bisect structures, the main pipe of heating medium inlet and outlet can be set inside or outside of shell
2.Airtight type: cylinder shell, capable of withstanding 5Kpa internal pressure, the main pipe of heating medium inlet and outlet can be set inside or outside of shell
3.Vacuum type: cylinder shell, design pressure is 0.1MPa external pressure, the main pipe of heating medium inlet and outlet can be set inside of shell
(4)Air Heater
It is usually used under the condition of larger evaporation to improve drying efficiency.
Technical parameters
|
|
Company introduction:
Changzhou No.2 Drying Equipment Factory Co.,Ltd is an old drying enterprise which has 23 years drying history. We have got several patents in different dryers. We have much experience in different drying area. Now it holds more than 100 sets of equipment. The company has more than 100 staff and workers, including 15 engineers, with annual value of production more than thirty-eight million RMB.We attach importance to advanced technology, and have cooperated positively with universities and colleges to develop new products by using new technics. We have continuously developed several key and high-tech products with advanced technology both from domestic and abroad.During the past ten continuous years, the company has been appraised as enterprise with high reputation on contract and credit.Bases on the principle of factualism, innovation and mutual benefit, the enterprise is looking forward to creating resplendence with personages from all circles together.
Certificate and Letters Patent:
Service:
The Warranty Period of the dryer machine shall be 12 months from the date of completion of the installation and commissioning of the Contract.
We will provide some spare parts for free together with dryer before shipping, paid service will be provided for the long term, and we can provide components at competitive price.
