Rotary Kiln Changzhou

Rotary Kiln Changzhou thumbnail-1
Rotary Kiln Changzhou photo-1
US$ 50,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drying Equipment
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Changzhou No. 2 Drying Equipment Factory Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drying Equipment
Place of Origin Jiangsu, China
Brand Name changgan
Model Number HZG
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

rotary kiln



rotary kiln Description
After the damp raw material is put into the drier from on end, it is turned over through strring-up rake inside the cylinder and distributed uniform in the drier and contacted with countercurrent hot air fully. It speeds up heat and mass conducting of dry. During the oeriod of dry, raw material is effcted by stirring-up rake with gradient and hot air, it can be moved and passed through the dry region and to star valve and then discharge the finished product.





rotary kiln Technical parameters

item(m) priductive capacity(t/h) revolution(r/min) motor power(Kw) install angle(.) Temp.of final
Φ1.0×5.0 0.5-1.2 0.6-6 4 3-5 ≤1.5%
Φ1.2×6-10 1.5-3 0.6-6 5.5 3-5 ≤1.5%
Φ1.5×12-18 3-5.5 0.6-6 15 3-5 ≤1.5%
Φ1.8×12-18 5-6.5 0.6-6 18.5 3-5 ≤1.5%
Φ2.2×12-22 7-12 0.6-6 22 3-5 ≤1.5%
Φ2.4×15-20 9-15 0.6-6 30 3-5 ≤1.5%
Φ3.0×25 16 0.6-6 55 3-5 ≤1.5%
model heat direct and sequence heat direct and retrograde compound heating
type of material mineral HP   ammonium sulphate phosphorus fertilizer coal
capacity kg/h 1000 -66 15000 20000 12000 5000
primary moisture % 30 13 6 1.5 5 6.5
final moisture % 15 0.3 1 0.1 0.1 0.1
average dim. mm 6.5 0.05 4.7 0.5-0.7 0.5 5
thickness of material mm 770 800 1890 1100 1500 750
capacity of hot air kg/h 39000 5400 10750 9800 6500 16000
temp. of air in 600 165 500 180 650 570
temp. of material out   42 100 70 80 75
heating style gas steam electric+heating heavy oil coal fuel furnace heavy oil heavy oil
ratio of feed   6.3 7 7.5 7.8 18
rotation speed rpm 4 4 3.5 3 4 2
angel . 0.04 0.005 0.03 0.05 0.05 0.043
quatity of oar 12 24 12 22 8
16		 6
12
dim. of drier m 2.0 1.5 2 2.3 2
0.84		 24
0.95
length of drier m 20 12 17 15 10 16
driving power kw 22 7.5 15 11 11 15



Company introduction:

Changzhou No.2 Drying Equipment Factory Co.,Ltd is an old drying enterprise which has 23 years drying history. We have got several patents in different dryers. We have much experience in different drying area. Now it holds more than 100 sets of equipment. The company has more than 100 staff and workers, including 15 engineers, with annual value of production more than thirty-eight million RMB.We attach importance to advanced technology, and have cooperated positively with universities and colleges to develop new products by using new technics. We have continuously developed several key and high-tech products with advanced technology both from domestic and abroad.During the past ten continuous years, the company has been appraised as enterprise with high reputation on contract and credit.Bases on the principle of factualism, innovation and mutual benefit, the enterprise is looking forward to creating resplendence with personages from all circles together.

rotary kiln Changzhourotary kiln Changzhourotary kiln Changzhourotary kiln Changzhou



Certificate and Letters Patent:

rotary kiln Changzhourotary kiln Changzhourotary kiln Changzhourotary kiln Changzhou



rotary kiln Changzhourotary kiln Changzhou

Service:

The Warranty Period of the dryer machine shall be 12 months from the date of completion of the installation and commissioning of the Contract.

We will provide some spare parts for free together with dryer before shipping,  paid service will be provided for the long term, and we can provide components at competitive price.
