Boiling Dryer

Boiling Dryer thumbnail-1
Boiling Dryer photo-1
US$ 3,000 - 90,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
chang gan, changgan
Model Number:
FG, FG
Contact Supplier Request Quote Chat Now
Changzhou No. 2 Drying Equipment Factory Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shangahi
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name chang gan, changgan
Model Number FG, FG
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

FG series vertical fluidizing dryer





Application
 boiling dryer is main used for drying powder or granules from pharmaceutical, foodstuff, chemical and so on industries.



Features
Fluid bed to achieve fast heat transmission of medium.
Seal negative pressure operation, there is no dust.
Because of using anti-static material as filter, it is safe in operation;
The equipment has no dead corner so it is easy to clean fully and there is no cross pollution.
It is in conformity with the requirements of GMR



Technical parameters

spec 3 5 30 60 120 200 300 500 1000
item unit
container of
raw material		 dim. mm 300 400 700 1000 1200 1400 1600 1800 2200
volume L 12 22 100 220 420 670 1000 1500 2500
production
capacity		 Min Kg/batch 1.5 4 15 300 80 100 150 250 500
Max Kg/batch 4 6 36 72 140 240 360 600 1100
consume of steam Kg/batch 12 23 70 140 211 282 366 465 800
amount of
compressed air		 m3/min 0.3 0.3 0.3 0.6 0.6 0.9 0.9 0.9 1.5
power of fan kw 2.2 4 5.5 11 18.5 22 30 45 75
temperature   Adjustable from ambient to 120
collection rate % >99
time of operation min 15~30(depends on material)
content of
final product		 % ~0.2(depends on material)
noise dB ≤75
height of
main machine		 mm 2100 2300 2500 3000 3300 3800 4000 4800 6200
