ZL15F EURO III emissions mini wheel loader | |
Model |
ZL15F |
Rated loading weight |
1500kg |
Rated bucket capacity |
0.8CBM |
Bucket width |
1800mm |
Track base |
1480mm |
Wheel base |
2005mm |
Min. swerve diameter |
4500mm |
Min. ground clearance |
260mm |
Dump height fully raised |
2600mm |
Reach fully raised |
1070mm |
Lifting time |
4s |
Hydraulic cycle time |
8s |
Max. tilt angle |
30% |
Max. bucket breakout force, lift cylinder |
36KN |
Driving mode |
Four-wheel drive |
Operating weight |
3600kg |
Dimension(L×W×H) |
4800*1770*2720mm |
Engine model |
498(EURO III emissions) |
Engine type |
In-line arrangement,water cooled,four-cycle diesel engine |
Engine starting mode |
Electric |
Rated speeds |
2400rpm |
Rated power |
36.8kw |
Brake mode |
Four-wheel hydraulic spread-shoed brake |
Color |
According to the requirements of customers |
Packaging details |
Nude package,3Units/40’s HC |
Delivery time |
25 days after confirm the order |
We can supply many types of loader.
Each type of loader has good quality and quick efficiency.
Welcome to inquire us.
