Manure granulator machine disk granulating/pan granulator machine/fertilizer pan granulating machine
The Manure granulator machine disk angle of the granulating machine is arc granulating ratio is over 93%.
The Manure granulator machine granulating disk has 3 mouths that are used to discontinuously produce granules, which reduces labor intension and improves labor efficiency.
Flexible straps turn motor and reducer steadily, which improve life.
The Manure granulator machine bottom is supported by several armor plates solidly.
Firm pedestal runs balanced. Thicker, heavier,solid base design, without anchor bolts fixed, smooth operation.
Manure granulator machine main gear is with high-frequency hardening, so the service life increased by one fold.
Grain face plate lined with high-strength glass fiber reinforced plastic, anti-corrosion and durable.
The Manure granulator machine surface has a uniform rate into the grain, smooth operation and durable.
Manure granulator machine is the best choice for your requirement.
The Manure granulator machine disk granulator fertilizer is best choice for organic fertilizer production line.
Manure granulator machine parameter
Model |
Inner diam |
Side height |
volume |
Rotation speed |
Motor power |
Prod capacity |
Decelerate motor |
SL25 |
2500 mm |
500 mm |
2.5 |
13.6 r/h |
7.5 kw |
1~1.5 t/h |
BW33-23 |
SL28 |
2800 mm |
600 mm |
3.7 |
13.6 r/h |
11 kw |
1~2.5 t/h |
BW33-23 |
SL30 |
3000 mm |
600 mm |
4.2 |
13.6 r/h |
11 kw |
2~3 t/h |
BW33-23 |
SL32 |
3200 mm |
600 mm |
4.8 |
13.6 r/h |
11 kw |
2~3.5 t/h |
BW33-23 |
SL36 |
3600 mm |
600 mm |
6.1 |
11.3 r/h |
15 kw |
3~5 t/h |
BW33-23 |
If you are interested in our machine,welcome contact with me.
