Specifications
1.low waste2.low consumption
3.high accuracy
4.high throughput
5.Have its own patented valve
*Description of color sorter :
1. The color sorter uses 2048 high performances CCD sensors with resolution up to 0.02 square millimeter.
2. The sorter adopts high quality special industrial lenses designed and manufactured for color sorting.
3. The high speed FPGA technology provides the sorter with fast detection and high identification rate.
4. Master control system adopts ARM high-end embedded processor, effectively enhance control speed and color selection precision.
5. Overall unit adopts intelligent closed-loop control.
6. The operation interface adopts industrial grade 7-inch TFT contact screen and features simple parameters setting and easy operation.
7. High speed air valve is used to ensure quick response, low power consumption and long service life.
8. Sorters use intelligent temperature and air pressure control technology in order to ensure the best operative mode for the whole machine.
9. Failure alarm automation and modular construction makes easy repair.
10.Business Cooperation: Most of the machine parts are imported(Altera CO.,LTD FPGA, Japan.Proface,CKD,SMC,Schneider).
*Detailed Parameters for the rice color sorter:
Model |
VSN3000-G4R |
VSN3000-G5R |
VSN3000-G6R |
VSN3000-G7R |
Channels |
256 |
320 |
384 |
448 |
|
Throughput (t/h) |
3.5~7 |
4.5~8 |
5~10 |
8~12 |
Accuracy |
> 99.98% |
> 99.98% |
> 99.98% |
> 99.98% |
Waste |
< 1: 0.125 |
< 1: 0.125 |
< 1: 0.125 |
< 1: 0.125 |
Voltage(v) |
~220V 50Hz |
~220V 50Hz |
~220V 50Hz |
~220V 50Hz |
Power(kw) |
2.5 |
2.8 |
3.1 |
3.4 |
|
Pressure (MPa) |
≥ 0.6 |
≥ 0.6 |
≥ 0.6 |
≥ 0.6 |
Consumption(L/min) |
1200~3000 |
1600~3500 |
1800~3800 |
2000~4200 |
Weight(kg) |
1000 |
1200 |
1400 |
1600 |
|
Dimension (L× W× H) |
1725× 1518× 1880 |
2025× 1518× 1880 |
2325× 1518× 1880 |
2625× 1518× 1880 |
*Machine show:
*Wheat:
*Exhibition:
*Components and parts of machine:
*Certificates of our company:
We also provide products include coarse cereal color sorters, tea color sorters and dehydrated vegetable color sorters, which can meet requirements of different customers on color sorting.
If you are interested in our products and wanna know more,please contact us.
What are you waiting for? Anhui Vision, your first choice.
Just do it! Come on!
