Help CenterAutomatic Buckwheat Color Sorter Machine, Vision's CCD Wheat Color Sorter Machine! With Japan Nikon Camera and Schneider Switch!
Related Products
-
Wheat CCD Color Sorter Machine, Wheat Cleaning Machine, Flour FactoryUS$ 30,000 - 85,000MOQ: 1 Set -
Wheat CCD Color Sorter, Wheat Machine, Flour Machine FactoryUS$ 30,000 - 85,000MOQ: 1 Set
-
Buckwheat Color Sorting Machine, Vision's CCD Wheat Color Sorter Machine! With Japan Nikon Camera and Schneider Switch!US$ 30,000 - 60,000MOQ: 1 Set
-
Wheat CCD Color Sorter Machine, Flour Machine, Agricultural MachineryUS$ 30,000 - 85,000MOQ: 1 Set
-
Wheat CCD Color Sorter, Wheat Machine, Flour Machine FactoryUS$ 30,000 - 85,000MOQ: 1 Set
Specifications
1.low waste & high accuracy2.Superb After-sale Service
3.passed ISO 9001 certificaton
4.Professional Technical Guidance
1. The color sorter uses 2048 high performances CCD sensors with resolution up to 0.02mm²;
2. The sorter adopts high quality special industrial lenses designed and manufactured for color sorting of buckwheat ;
3. The high speed FPGA technology singal processor with fast detection and high identification rate;
4. Master control system adopts ARM high-end embedded processor, and effectively enhances. Control speed and color selection precision;
5. Overall unit adopts intelligent closed-loop control;
6. The operation interface adopts industrial grade 7-inch TFT contact screen and features simple parameters setting and easy operation;
7. High speed air valve is used to ensure quick response, low power consumption and long service life;
8. Sorters use intelligent temperature and air pressure control technology in order to ensure the best operative mode for the whole machine;
9. Failure alarm automation and modular construction makes easy repair;
10.Business Cooperation: Most of the machine parts are imported(Altera CO.,LTD FPGA,Japan.Proface,CKD,SMC,Schneider).
Product Model/Technical parameter:
Model | VSN3000-G4R/C4R/G4A/C4A | VSN3000-G5R/C5R/G5A/C5A | VSN3000-G6R/C6R/G6A/C6A | VSN3000-G7R/C7R/G7A/C7A |
Channels | 256 | 320 | 384 | 448 |
Capacity (t/h) | 3.5~7
| 4.5~8
| 5~10 | 8~12 |
Accuracy | >99.98% | >99.98% | >99.98% | >99.98% |
Waste | <1:0.125 | <1:0.125 | <1:0.125 | <1:0.125 |
Voltage(v) | ~220V 50Hz | ~220V 50Hz | ~220V 50Hz | ~220V 50Hz |
Power(kw) | 2.5 | 2.8 | 3.1 | 3.4 |
Pressure(M Pa) | ≥0.6 | ≥0.6 | ≥0.6 | ≥0.6 |
Consumption(L/min) | 1200~3000 | 1600~3500 | 1800~3800 | 2000~4200 |
Weight(kg) | 1000 | 1200 | 1400 | 1600 |
Dimension(L×W×H) | 1425×1518×1880 | 1725×1518×1880 | 2025×1518×1880 | 2325×1518×1880 |
