Full automatic control 4m-30m length cca acq preservative pressure wood treatment equipment
1. The usage of wood treatment equipment
- Wood pressure treatment equipment can be used for wood preservation, wood flame-resistant, wood coloring, mainly for timbers. The wood can be used for 15-50years, the wood can adapt to all kinds of environment.
- Wood pressure treatment equipment apply to be preservation, termite proof and to prevent fungal.
Specification |
Volume |
Treatment volume |
Pressure |
Vacuum degree |
mm |
M³ |
M³ |
Bar |
Mpa |
DN1200*8000 |
9.6 |
7.0 |
12.5, 13, 16, 25 |
0.098 |
DN1500*8000 |
15.6 |
11.0 |
||
DN1800*8000 |
21.6 |
16.5 |
||
DN2000*8000 |
27 |
21.0 |
||
DN2400*8000 |
40 |
25.0 |
Parameter range:
1) Working pressure: -0.08MPa--3.6MPa
2) Working temperature: 0--200°c
3) Vocuum degree(relative): 0.098MPa
4) Capacity ( one time ): 2 / pot--20 /pot
5) Length: 6-50m
6) Diameter: 1-5m
3. The working principle of wood treatment equipment
Working processes:
- Inicial vacuum: suck air out of tank and wood with vacuum pump and keep the vacuum status 15minute to 1 hour according to treatment aims. Vacuum status is good for agent liquid goes into wood.The vacuum degree can be 0.098MPa.
- Agent liquid adding: under condition of vacuum pump agent liquid into tank.
- Pressurizing: when tank is full of agent liquid, pressurize tank with pressure pump. The pressure inside tank will rise slowly to rated pressure.Then keep the tank under rated pressure until wood have absorbed enough agent liquid.
- Pressure discharging: when wood have absorbed enough agent liquid,discharge inside pressure and agent liquid that have not been absorbed.
- Final vacuum: when the rest agent liquid has been discharged,suck air out of tank and wood with vacuum pump again to make redundant.Agent liquid exude from wood. cells or surface to avoild liquid drops.
4. 3D drawing of wood treatment equipment
5. Installation of wood treatmnet equipment
6. The delievry of wood treatment equipment
7. Productions in our workshop of wood treatment equipment
8. ABOUT HUATAI CEREALS&OILS MACHINERY CO.:
♦ More than 60 years manufacture histories.
♦ Largest oil machine manufacturer in China.
♦ 100,000 m² of factory total area and 580 senior engineering technicians.
♦ 23 National patents.
♦ 87 million yuan fixed assets.
♦ 150 million annual sales turnover.
9. HUATAI COMPANY ADVANCED EQUIPMENTS:
10. HUATAI CUSTOMERS VISITING OVER THE WORLD:
11. STATE LEADERS VISITING TO HUATAI:
12. HUATAI OVERSEA EXHIBITION:
If you want to know more information about our project, Please Leave Message on below form and click "send" below. I will reply to you. Thanks!
