Vsee Belt Color Sorter

Description

♦ Vsee nut CCD color sorter

1. The color sorter uses 2048 high performances CCD sensors with the definition up to 0.02mm² and thus is able to detect fine color differences of materials in parts.

2. The sorter adopts high quality special industrial lenses designed and manufactured for color sorting of coarse cereals, dehydrated vegetables and plastics. The working parameters of the lenses are customized for color sorting of different materials with optimized light path design to ensure that each grain of materials can be imaged on the image sensor.

3. The high speed FPGA technology provides the sorter with fast detection speed and high identification rate. The special coarse cereal detection algorithm is designed according to the spectrum characteristics and identification characteristics and emphasizes on both sensitivity and robustness to meet requirements on fine color difference detection and increase the robustness to prevent interference by other factors on material surfaces.

4. Master control system uses ARM high-end embedded processor to effectively increase the control speed and color sorting precision.

5. The complete sorter applies intelligent closed-loop control. The industrial grade data bus ensures the reliability of communication and the control system and provides powerful interference resistance capability.

6. The operation interface adopts industrial grade 10-inch TFT contact screen and features simple parameter settings and easy operation. The color inter face provides great vividness.

7. High speed air valve is used to ensure quick response, low power consumption and long service life.

8. The sorter machine has various working modes to meet requirements of various coarse cereals such as melon seeds, sunflower seeds, millets, beans, dried grapes and peanuts and dehydrated vegetables such as peppers and garlic pieces, thus has common applicability, high sorting precision and low carryover rate.

9. The sorter uses intelligent temperature and air pressure control technology to ensure the best working state. The sorter is equipped with automatic fault alarming and the modularized structure for easy repairing and maintance.

♦ Famous Brand Parts: Pro-face Touch Screen, Nikon CCD Camera, Schneider Electric, SMC Air Filter, CKD Air Filter

 Sorting Examples

♦ The following samples are for your reference:

Grain color sorter: Sesame seeds, sunflower seeds, soybeans, corn, peaunts, wheat, broad bean, mung beans, raisin, barley, oats, buckwheat, millet, red beans, black beans, kidney beans etc.

Technical Parameter

♦ nut color sorter VSN3000 Series

Note: The above parameters vary with types, shapes and grain sizes of raw materials and defect rate. Please consult the sales staff before buying.

Necessary Accessories
