WHERE THERE IS BEST, WHERE THERE IS BETTER
1, High reliability
The optimized system structure, minimizes the complexity of the machine, and improves the reliability of the machine.
2, Advanced camera image acquisition system
Unique 5000 pixel, 3 CCD, true color colorful CCD chips, high-speed high resolution linear CCD camera,which can distinguish the heterochromatic area smallest up to 0.025mm2 , very accurate.
3, Intelligent image processing algorithm
Special intelligent algorithms, world sole rapid and big data communication, implement special treatment for tiny spots, yellowish material, etc. to improve sorting accuracy.
4, World Famous Ejectors
Using world famous ejectors,1000times per second high-frequency, 10 billion times long working life, low air consumption to guarantee the big capacity, excellent rejection output.
5, LED light source
The LED light source, long life, more energy-efficient.
6, Multi-language 10.4” Touch Screen
Friend Human Machine Interface, easy and simple to operate.
7, Enable more applications, multi-function
Various materials can be sorted, and one machine can be used for sorting several similar materials, more flexible.
Technical Specifications:
Item |
B600 |
B900 |
B1200 |
Model No. |
CSB-600 |
CSB-900 |
CSB-1200 |
Belt width (mm) |
600 |
900 |
1200 |
Weight (kgs) |
900 |
1100 |
1300 |
Light source |
LED |
LED |
LED |
Pixel of camera |
5000*3 |
5000*3 |
5000*3 |
|
Processing capacity (t/h) according to impurity |
2.0-4.0 |
3.0-6.0 |
4.0-8.0 |
Sorting accuracy |
≥99.95% |
≥99.95% |
≥99.95% |
Carryover rate |
≥9:1 |
≥9:1 |
≥9:1 |
Main machine power |
2.2 |
2.6 |
3.0 |
Air pressure |
≥0.6Mpa |
≥0.6Mpa |
≥0.6Mpa |
Air consumption (L/min) |
600-2000 |
700-2500 |
800-3000 |
Power supply (V/Hz) |
The voltage/ hertz can be adjusted to meet requirement according to different area |
||
