Skin Tightening Ipl Rf Skin Tightening Machine Skin Rejuvenation

How it works

IPL (Intense Pulsed Light) is a kind of light with high energy and broad wavelength, within the range

from 420nm to 1200nm. Intense Pulsed Light with broad spectrum affects pigmentations, vascular

lesions and hair follicles. Photochemical and photochemical action will be triggered by the radiation of IPL.

Pigment is shattered and eliminated out of body through metabolism. Meanwhile, IPL will also promote collagen production, which can make the skin more flexible and smooth. The light with long wavelength can easily pass through epidermis layer to the hair follicles in the deep skin layer. At the targeted area,high energy occurs to destroy follicles and hair shaft, preventing regrowth of new hair. With a series of treatment, IPL technology can help restore a more youthful appearance without downtime and side effect.

Specifications

2. Pigment Removal
3. skin tightening machine
4. Wrinkle Removal
5. Red Vascular Therapy

Specifications:



Principle:

E-light:
Through light pyrolysis principle, using intense pulsed light can act directly on the skin, make skin lesions on the solar energy selective absorption to the treatment of a variety of tissues, and do not damage normal skin tissue.
RF:
RF through the skin directly in the dermis, activation of dermal cells allow water molecules are high-speed vibration friction energy, when the local to about 60 °C (subcutaneous gusts of warm sense) dermal collagen immediately convergence and activation of long term growth so as to improve the convergence of the skin and anti-aging effect of living color.

Light Source	Intense Pulse Light(IPL), 5 times the Atmospheric Pressure Xeon lamp
Spot Size	12*40 mm² or 12*50mm²or according to your requirments
Frequency	1,2,3,4,5 Hz
Energy Density	0-50j / cm²
The First Pulse-width:	1-50ns (Adjustable)
Pluse Sequence	1-50ns (Adjustable)
Pulse Interval	1-100ns (Adjustable)
Pulse Number:	1~99 pcs
Power Supply	220V/110V
Power Output	1000w
Cooling Temperature	0°C ~ -8°C(Adjustable)
Cooling System	Simiconductor+Water+Wind
Handlepiece	One Handpiece, 3 filters
Spectrum Range	480nm/530nm/640nm(Optional)
Program Langurages	English, Chinese
LCD Screen	Blue, 5.7"
Dimension of Machine	50cm*35cm*80 cm
N. W.	48KG
Package	Aluminum Alloy or according to your requirments



Picture of Screen:







What is IPL Skin Rejuvenation?
IPL is a kind of photon therapeutic apparatus, also called IPL photo rejuvenation. It is widely used for skin rejuvenation, hair removal and pigmentation removal with the therapeutic mechanism of thermal selective effect. It is a kind of non-abrasive photodynamic therapy, making use of insignificant amount of intense pulsed light technology to conduct non-abrasive skin rejuvenation therapy with low energy and density, to achieve the purpose of rejuvenating and beautifying the skin.



Main Applications:

1. Hair Removal
2. Pigment Removal
3. Skin Rejuvenation/Whitening
4. Wrinkle Removal
5. Red Vascular Therapy



Portable Elight = IPL + RF beauty equipment



Two System RF IPL beauty equipment

The portable machine is combination of Elight and RF system in  one machine

Elight with 3 filters mainly function for hair removal ,skin rejuvenation,

acne pigmentation treatment

RF with 3 treatment tip for skin lifting,tighten flabby skin .wrinkle removal etc

Treatment Applications:

1.530nm/To remove freckles,age spots,sunburn,such pigmentations treatment.



  spots removal

2.480nmTo treat acne,pimples,improve the situation of oily skin.

      treat acne



3.640nm /To remove unwanted hair on any part of body:dark&thick hair,light-colored&soft hair.

   hair removal

4.skin rejuvenation :530nm/To rejuvenate skin:tighten skin,lifting skin,improve elasticity of skin;
To remove fine wrinkles;To whiten skin,contract large pores.

5.Remove vascular lesions:480nm/To Remove vascular lesions:angiotelectasis



Accessories



After sale service:



1. We supply one year warranty for the main frame. For other parts or parts over warranty, we supply repairing service and maintenance too, but we would ask for some charges for the service and replacement parts.

2. We will not supply warranty if any following condition.

a. There is a malfunction caused by disassembly the machine without our permission.

b. There is a malfunction caused by not carefully use (fall down or shock the machine).

c. There is a malfunction caused by no maintenance.

d. There is a malfunction caused by incorrect operation.





IPL applications

1. Hair removal: Remove unwanted hair in different depths and thickness;
2. Skin rejuvenation, contract the pores and remove black heads;
3. Effectively remove all kinds of pigment, such as a freckle, deep-seated speckle, cuticular speckle, corium speckle, age pigment and chloasma;
4. Remove facial vascular lesions (Telangiectasis or pathological capillary vessel);
5. Remove acne on face and body effectively;
6. Dispel wrinkle, tighten skin, and lift face;
