Newly Designed High Power 808nm Diode Laser Hair Remove Machine With CE Certification

 1.Working Principle

1.Diode laser hair removal technology is based on the selective dynamics of light and heat.

2.The laser goes through the skin surface to reach the root of hair follicles.

3.Light can be absorbed and converted into heat damaged hair follicle tissue, so that hair loss regeneration without injury surrounding tissue.

4.Slight pain, easy operation, the most safe, technology for permanent hair removal now.

5.Diode laser equipment adopts 808nm, particularly effective to hair follicle melanocytes without injury surrounding tissue.

6.The laser light can be absorbed by hair shaft and hair follicles in the melanin, and converted into heat, thus increasing the hair follicle temperature.

7.When the temperature rasises high enough to irreversibly damage the hair follicle structure, which disappear after a period of natural physiological processes of hair follicles and thus achieve the purpose of permanent hair removal.

2.Characteristics

1. Permanent remove the unwanted hair of all the parts of the body, such as face,    armpit, back, legs and bikini line, etc, and removal all kinds of depth hair.

2. Effectively remove all kinds of hair colors, like black, brown, russet, etc.

3. No pain, no surgery, no down-time needed, no influence to the daily life and work.

4. Non-invasive treatment with high safety

3.Specifications

4.treatment

1. Hair removal for all skin types, cause the wavelength is near infrare, so it won't cause skin damage for dark skin type, and with long pulse width, even the darker skin can get good treating result.

2. Skin rejuvenation.

5. Advantages

1), Handle and Pipe

10 Germany “Dilas”laser bar inside,60w for each total power can reach 600W.

High quality Medical pi pe for water circulation,soft with good flexibility,durable.

2), Big spot Size

12*20mm big spot,quicker your treatment time.Nubway spot size is exclusive in China

3),  Big Output Energy

Max laser total output energy can reach 168J,average 70J/cm2 on the skin,effective result confirmed

4), Strong Cooling system

Semiconductor+ Water+ Air Cooling triple cooling systems

10L big water tank, booster pump ,which can output 6.5L water per min, high lift can reach 60 meter, ensure good water circulation;

2 big Copper Radiator ,better heat conduction than the Aluminum ;4 big DC fan 12V, big wind , the heat can be soon disappeared ,also low power , low noise.

Strong cooling system guarantee our machine can working continues 12 hours more

5), Main power supply

Our main power supply is special custom-made , which is totally fit for this machine , not the general power.

The output current is constant current , which will avoid the damage to the bar as the electric current is too strong. But many manufacturer just use the ordinary magnetic drive pump , it will usually led the strong current directly to damage the bar.

6),  Two water filter

This machine is equipped with two water filter. The small one is used to catch impurities, and the big one is specialized to filter the ion in the water , which can prevent the scale forming after the water heating .

Most machines don’t have this ion filter , which will cause the machine jams , even blocking the bar, This will seriously affect the working life of machine. specially for the electrode.

6. Machine Show

User interface

7.Detail pictures

Side view

Services :

Our Factory:
