Big Power Beauty Machine! Multifunction Laser rf Ipl Elight

Elight function

Multi-band hand-piece

480/530/560/580/640~1200nm (Standard)
430/690/750~1200nm (Option)

Energy density

10-50J/cm2(adjustable)

Frequency

2s, 3s, 4s

Pulse Number

1-15 pulses(adjustable)

Sub-pulse Width modulation

0.1-9.9ms(adjustable)

Pulse Space

0.1-99.9ms(adjustable)

RF Frequency

1-10MHZ

RF Energy

0-50 J/cm2(adjustable)

Light Spot Area

12*35mm2/ 8*40mm2 /15*50mm2(IPL+RF)

Cooling system

Semiconductor+ wind + water +cooling gel+ sapphire filters

IPL Function

Multi-band hand-piece

480/530/560/580/640~1200nm (Standard)
430/690/750~1200nm (Option)

Spot Size

12*30mm2/ 8*40mm2 /15*50mm2

Light Source

Six times atmospheric pressure

Energy Density

0-50J/cm2

Frequency

2s, 3s, 4s

Pulse Number

1-15 pulses(adjustable)

Sub-pulse duration

0.1-10ms

Pulse Space:

0.1-100ms (adjustable)

Cooling system

Semiconductor+ wind + water +cooling gel+ sapphire filters

RF Function

RF output

Bipolar rf

RF frequency

6MHZ

RF Energy

20~100 J/cm3

RF Input Power

500W

RF Output Powe

200W

Cavitation Function

Cavitation frequency

40.5KHZ

Cavitation max ourput

100W

Cavitation power

0~5 W/CM2

ND yag laser function

Wavelength

double wavelength 1064nm, 532nm

Single-pulse Energy

1500mJ (1064nm); 400mJ (532nm)

Width of pulses

 <15ns

Frequency

1-10HZ(adjustable)

Diameter of spot

1-7mm

Beam of light transmission

7 articular-arm of light guide transmitting, transmission power is more than 75%

The light spot diameter of the laser output

3mm

Cooling manner

Closed-off water circulation + air
