IPL Intense Pulse Light Aesthetic Instrument

Specifications

Intense Pulse Light
*IPL Hair Removal
*IPL Skin Rejuvenation
*IPL Acne Clearance
*IPL Spot Removal

IPL Intense Pulse Light Aesthetic Instrument



Principle

The new intelligent control system (integrating E light:PL & RF system, IPL System and RF System), a unique system in the world.

Seperate E light IPL & RF system, IPL System, RF system; can be used as a single system machine, same output energy level, same treatment results.

Spend little money and offer more treatments, greatly save on the costs and offer more bigger benefits, more convenience to a buyer.

Applications





Applications

1. Deeply wrinkle removal and face lifting

2. Unwanted hair removal: take advantage of intensive pulsed light and RF energy (could act on skin below 8 mm), act on the pore directly to remove the thick dark hair, and lighten tiny hair

3. Dermic spots, pigment and red blood streak removal

4. Acne treatment: reducing the activities of sebaceous gland

5. Breast lifting



Features

1.8.4 inch touch colour LCD screen, comfortable and elegant

2. Adopts the most advanced plug and play device in the world, integrating the automatic water and electricity protection, making the installation and operation more easy, safe and reliable

3. Unique and exclusive "air switch", which has a quick reaction than fuse, greatly make the operator, patients and device safe.

4. Bigger power output

5. Light design in plastic for lighter weight & portability

6. Wide range of treatment, great effect, and with high safety factor

7. Unique technology over the worldwide.

8. Combined with E light (IPL+RF), IPL and RF machines together, and it has Two different hand pieces, three separate systems.

9. Easy to operation, safer when treatment



Technique Data

E light System (IPL+RF system)	Multi-band hand-piece	5 wavelength 480/530/590/610/690nm
	Handle number	1 handle
	Energy density	10-50J/cm2
	Frequency	2s, 3s, 4s
	Pulse Number	1-6
	Sub-pulse Width modulation	1-25ms
	Pulse Space	1-100ms
	RF Frequency	2-6Mhz
	RF Energy	0-50
	Light Spot Area	12*30mm2/ 8*40mm /15*50mm
	Cooling System	Semiconductor+ wind + water +cooling gel
IPL System	Spot Size	15x50mm2
	Handle Number	1 handle
	Light Source	Six times atmospheric pressure
	Energy Density	12-50J/cm2
	Frequency	2s, 3s, 4s
	Pulse Number	1-15
	Sub-pulse duration	0.5-10ms
	Pulse Space	1-50ms
	Cooling System	Semiconductor+ wind + water +cooling gel
RF System	Spot Size	16/32mm (dia.)
	Handle Number	1 handle
	RF Frequency	0.1-6MHz
	RF Energy	0-50
Specification	Screen	8.4 inch color touch LCD display
	Language	English, Spanish, Italian, German, French
	Voltage	220V(110V)/15A 50Hz(60Hz)
	Output Power	1300W
	Size of Machine	62cmx44cmx50cm(L x W x H)
	N/G Weight(Kgs)	20/30Kgs
