single Channel pet clinic /hospital veterinary Vet use EKG ECG Machine

FOB Price

USD $250 - $360 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Beijing
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Type:	Other	Brand Name:	Brandnew	Model Number:	EKG-901V-2
Place of Origin:	Beijing, China

Product Description

single Channel pet clinic /hospital veterinary Vet use EKG ECG Machine

Features:

High-resolution thermal printing array system

Frequency response is as high as 150Hz

Capable of printing continuously on channel trace and annotations including lead mark and parameter such as sensitivity, paper speed and filter operation status

High resolution digital filter inhibits baseline drift without affecting ECG waveform

One-touch operation

Concept of floating input circuit meets IEC safety standard

Rechargeable battery supporting more than 50 patient examinations

Lead Standard: 12 leads

Specifications

Input Circuit	Floating; Protection against Defibrillator effect
Lead	Standard 12 Leads, Lead change automatically
Patient Current Leakage	<10μA
Input Impedance	≥10ΜΩ
Calibrating Voltage	1mV±3%
A/D Conversion	12 bit
Frequency Response	0.05Hz~150Hz (IEC)
Time Constant	>3.2seconds
CMRR	>80dB >100dB (with filter)
EMG Filter	35Hz (-3dB) / 25Hz (-3dB)
Sensitivity	1/2, 1, 2 (cm/mV), Conversion Deviation≤5%
Recording System	Thermal-array 8 dots/mm ( vertical ) 16 dots/mm ( horizontal, 25mm/sec )
Paper Speed	25, 50mm/s±3%
Recording Paper	50mm,20m, high-speed roll
Input Circuit Current	≤50nA
Safety Standard	IEC class I, type CF
Power Supply	AC: 220V / 110V, 50/60Hz DC: 12V rechargeable battery
Skin Voltage Tolerance	±300mV
Noise Level	<15uVp-p
Dimensions	310mm×230mm×70mm
Dimension of Packing	400mm×280mm×160mm
Weight	2.75kg

Click the link for more products:
http://jxkh.en.china.cn/productgrouplist-801164721/Veterinary.html

Contact information

Company Information

Our Services

1. 18 months warranty for the mainframe from date of shipment under normal use and service.

2. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the equipment, and after-sale maintenance and more.

3. Carejoy Medical provides free technical & service training to the technical & sales staff of distributors for the related products and will further provide technical assistance via e-mail, Skype as requested by the distributors. The training will be performed in Beijing China.

4. OEM/ODM services are available.
