Large Screen Good Image Full Digital Portable Ultrasound Scanner Machine with Probe-External Workstation (80 element)
Features:
Full digital imaging technology
DBF: Digital Beam Forming
RDA: Real-time dynamic aperture imaging
DRA: Dynamic real-time acoustic apodizer
DRF: Dynamic receiving focus
DFS: Dynamic frequency scanning
- Ensure that the image is not distorted, edge clearer, level richer.
- Humanized operating design.
- 8 sections TGC gain adjustment.
- With abundant built-in software packages.
- Comprehensive software measurement capabilities, to allow more extensive clinical application.
- Two probe/three probe connectors (optional).
- Probe connected with a variety of choice to achieve maximum functionality.
- Excellent value for money.
- VLSI, advanced technology, stable performance.
- Reasonable cost control, to achieve the perfect embodiment of price and performance.
Specification:
Image mode: B, B/B, 4B, B+M, M
Image magnification: *0.8, *1.0, *1.2, *1.5, *1.8, *2.0
Local zoom: 2 times local zoom in real time
Dynamic range: 64dB – 96dB adjustable
Focus: 4-segments dynamic electronic focuses selected
Gray scale: 256
Pre-processing: variable aperture, image direction, dynamic filter, edge enhancement, etc.
Post-processing: digital space time filter, 8 y corrections, 16 Pseudo Colors, column correlation, frame correlation, spot correlation, linear interpolation, etc.
Multi-frequency: 2.5MHz/3.0MHz/3.5MHz/4.0MHz etc. Multi-frequency selected.
Measurement: distance, circumference/acreage, HR, pregnancy week (BPD, GS, CRL, FL, AC) and calculating fetus weight, etc.
Annotation: Chinese/English interface transition; hospital name, doctors/patients name, case number, gender, age; 16 body marks with probe location, full screen character annotation, real time clock display.
Puncture lead: Image B: Puncture guide line under B mode.
Gain adjustment: 8-segments TGC adjustment, GAIN adjustment or near field, far field, overall gain adjustable.
Image reverse: left/right, black/white, up/down.
Storage: 128 images permanent storage.
Cine loop: 256 images real time display cycling/one-by-one checked.
Output interface: 2 SVGA video outputs, SVGA color monitor circumscribed; 2 PAL video outputs, which can be connected with PAL standard monitor, Video thermal recorder, ultrasound image workstation, etc.
Optional features: multiple probes connectable, USB port, Video thermal recorder.
Probe connectors: 2 socket, multiple probes connectable.
Standard configuration:
- 12-inch LCD monitor
- 2 probe connector
- 1 USB
- 80 elements R60, 3.5MHz multi-frequency convex probe
- Optional:
- High frequency linear probe
- Electronic trans-vaginal probe
- Rectal probe
- Video thermal recorder
- 3D Ultrasound image working station, etc.
Details show:
Package: Standard export carton.
Payment & Delivery:
T/T, West Union & Paypal.
Shipping: DHL, UPS or TNT etc, arrive in 3-5 working days.
Air shipping & sea shipping are also available.
Warranty: 18 months upon delivery.
1. 18 months warranty for the mainframe from date of shipment under normal use and service.
2. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the equipment, and after-sale maintenance and more.
3. Carejoy Medical provides free technical & service training to the technical & sales staff of distributors for the related products and will further provide technical assistance via e-mail, Skype as requested by the distributors. The training will be performed in Beijing China.
4. OEM/ODM services are available.
