Laptop 15 inch LCD Color Doppler Ultrasound Diagnostic System RUS-9000-2 with CE ISO approved
Display mode:
B&W mode: B, 2B, B/M, 4B
Color Doppler mode: CFM, PDI, PW
Duplex: Real-time simultaneous 2D, Doppler
Gray scale: 256
Display: 15 inches LCD monitor
Transducer frequency: 2.5-10 MHz
Digital technology: Dynamic Receiving Focusing (DRF
Dynamic Frequency Scanning (DFS)
Scanning depth: 300mm
Technical Specification:
Imaging Processing
Pre-processing: 8-segment TGC
Preset
Gain (B&W, Color, Doppler)
Audio
PRF
Dynamic Range
Image enhancement
Acoustic Power
Post-processing: gray map
Black/white reverse
Left/right reverse
Up/down reverse
Functions:
Cine-loop: 1000 frame cine loop memory
Storage media: 64G massive image-storage capacity
Zoom: Pan Zoom
USB ports: 2
THI: tissue harmonic imaging
ITouch
IClear Imaging
Measurement & Calculations:
B mode: distance, circumference, area, volume, angle, fetal growth, cruve
M mode: distance, time, velocity, heart rate
Software package: abdomen, gynecology, obstetrics, cardiology, small parts, urology
Others
Transducer connectors: 1 active transducer connector ports
Peripheral ports: video, S-video, VGA, 2 USB ports, Diom ports
Power supply: 100~240VAC+_10%, 50Hz/60Hz
Packing List:
1 Main unit
1 Convex probe
1 Linear arry probe
1 Power cable
1 User’s manual
Click the picture for more information:
1. 18 months warranty for the mainframe from date of shipment under normal use and service.
2. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the equipment, and after-sale maintenance and more.
3. Carejoy Medical provides free technical & service training to the technical & sales staff of distributors for the related products and will further provide technical assistance via e-mail, Skype as requested by the distributors. The training will be performed in Beijing China.
4. OEM/ODM services are available.
