cheap price Portable Ultrasound scanner with battery aluminium box suitable hospital clinic

Product Name: Handheld Ultrasound Scanner

Model:  HandScan H8

Introduction for the HandScan H8:

HandScan V8 is the latest model. It is distinguishable by its bright and clear image quality.

The interchangeable probes offer a wide range of diagnostic applications.This equipment is Suitable for family doctors, veterinary scanning.

The complete software and the high product versatility are available in it. which is high resolution linear/convex ultrasound scanning diagnostic equipment. It adopts microcomputer control and digital scan converter (DSC), digital beamforming (DBF), real time dynamic aperture (RDA), real time dynamic receiving apodization, real time Dynamic receiving focusing (DRF), Digital frequency Scan (DFS), frame correlation technologies to endue its image with clarity, stability and high resolution.

Features for Digital PalmSmart Ultrasonic Scanner:

1. 5 inches TFTLCD display and programmable device (FPGA) and surface mounted technology (SMT) make this device compact and light in weight.

2. Battery: AC adapter,and Liion battery, 3 battery charging modes enable more lasting battery.

3. Display modes: B, B+B, B+M, M; Can realize image real time display.

4. Jet molding enclosure with hand-held structure makes it convenient for out diagnoses.

5. The device consists of mainframe, probe and adapter.

specifications:

  Display Modes          B,B+B,B+M,M,4B

  Frequency:             2.5MHZ-7.5MHZ

  Scanning Depth:         70mm~220mm

  Gray Scales:              256levels

  Cine locp:            >=400frames

  Image Storage:  Built-in memory-64 images USB disk storage

  Image Reservationg: up/down,left/right

  Image Conversion:  distance,circumference,area,volume,EF   rate,heart

 Measurements:  rate,Time

 OB Measuremengts:

 BPD,GS,CRL,FL,HC,AC,EDD,GA,FWVIDEO(PLAD,NTSC),USB2.0

 Monitor:   5.5 inch TFT color LCD

 body markers: A variety of body markers(40 sorts)

Standard Configuration:

  One(1)Main unit

  One(1)R40/3.5mhz Convex Probe

  One(1)AC-Adaptor

  One(1)Rubber Protector

  One(1)Rechargeable Battery

  Two(2)shouider and waist beits

  ALL above will be packed in a carrying case

  Comments: date&time,name,sex,age,hospital

  Applications:Professional sofeware package in Obstetrics,Gynecology,Urology and Small parts

  Weight:  700g

  Dimensions: 230mm×120mm×42mm

  Battery working:>3 hours

Optional:

  probes: R40/5.0mhz Micro-convex Probe

           L40/7.5Mhz HF linear Probe

           R10/6.5MHz Transvaginal Probe

  Biopsy

  Car Lighter

  Additional rechargeable battery
