Hot Selling Computer Style Portable 8.4 Inch Patient Monitor Multi Parameter ECG, NIBP, SPO2, PR
US$ 500 - 900
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Brandnew
Place of Origin:
Beijing, China
Model Number:
RPM-9000C
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing or Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Economic Price New Medical Device 8-inch Portable Multiparameter Patient Monitor for HospitalUS$ 300 - 800MOQ: 1 Set -
Multi-functional Dual TEMP IBP ETCO2 Printer Thermal Recorder Trolley Optional 15 Inch 6 Parameter Patient MonitorUS$ 500 - 900MOQ: 1 Set
-
China Factory Sale Medical Equipment Handheld 7 Inch 6 Parameter Patient Monitor With Capnography Optional PrinterUS$ 280 - 380MOQ: 1 Set
-
2016 New Pattern Touch Screen,5.0 Inch Color TFT -LCD Display Patient Monitor With Bluetooth FunctionUS$ 160 - 680MOQ: 1 Set
-
Hot Product Ambulance 12 Inch Multi Parameters ICU Patient Monitor Applicable for Hospital OperationUS$ 600 - 800MOQ: 1 Set
Brand Name
Brandnew
Place of Origin
Beijing, China
Model Number
RPM-9000C
Hot Selling Computer style Portable 8.4 inch Patient Monitor multi parameter ECG, NIBP, SPO2, PR
Product Description
Features:
- 8.4” color TFT display
- Unique digital SPO technology with excellent measurement and interference-free
- Audible and visual alarms with adjustable alarm range
- Anti electrosurgical interference and defibrillation
- Can be connected with LAN to work with central monitoring system
- Powerful data management and storage capacity
- Suitable for adult, pediatric and neonatal patient
Standard configuration:
- ECG, NIBP, SPO2, PR, Built-in rechargeable battery
Optional:
- RESP, TEMP, 2-TEMP, 2-IBP, ETCO2, Thermal printer
Technical Specifications:
ECG:
- Lead Mode: 5 Leads (R, L, F, N, C or RA, LA, LL, RL, V)
- Lead selection: I, II, III, avR, avL, avF, V
- Waveform: 2 ch
- Gain: 2.5mm/mV, 5.0mm/mV, 10mm/mV, 20mm/mV
- HR and Alarm Range:
Adult: 15 ~ 300 bpm
Neo/Ped: 15 ~ 350 bpm
Accuracy: ±1% or ±1bpm, which great
Resolution: 1 bpm
Sensitivity: >200uV P-P - Differential Input Impedance: >5MΩ
- CMRR:
Monitor: >105dB
Operation: >105dB
Diagnosis: >85dB - Electrode offset potential: 300mV
- Leakage Current: <10uA
- Baseline Recovery: <3s after Defi.
- ECG Signal Range: 8mV(Vp-p)
- Calibration Signal: 1mV (Vp-p), 5% Accuracy
- ST Segment measure and alarm: -2.0 ~ +2.0 mV
NIBP:
- Method: Oscillometry
- Mode: Manual, Auto, STAT
- Measuring Interval in AUTO Mode: 1, 2, 3, 4, 5, 10, 15, 30, 60, 90Min
- Measuring Period in STAT Mode: 5 Min
- Pulse Rate Range: 40 ~ 240 bpm
- Alarm Type: SYS, DIA, MEAN
- Measuring and alarm Range
Adult Mode:
SYS: 40 ~ 270 mmHg
DIA: 10 ~ 215 mmHg
MEAN: 20 ~ 235 mmHg
Pediatric Mode
SYS: 40 ~ 200 mmHg
DIA: 10 ~ 150 mmHg
MEAN: 20 ~ 165 mmHg
Neonatal Mode
SYS: 40 ~ 135 mmHg
DIA: 10 ~ 100 mmHg
MEAN: 20 ~ 110 mmHg
Resolution: 1mmHg - Over-pressure protection: YES
SPO2:
- Measuring Range: 0 ~ 100%
- Alarm Range: 0 ~ 100%
- Resolution: 1%
- Accuracy:
70% ~ 100%: 2 %
0% ~ 69%: unspecified - Actualization interval: About 1Sec.
- Alarm Delay: 10 Sec.
- Pulse Rate
Measuring and Alarm Range: 0~254bpm
Resolution: 1bpm
Accuracy: 2bpm
Alarm Delay: 10 Sec.
