New!!! Full Digital Portable Ultrasound Scanner (PC) With Low Price

Name: New!!! Full Digital Portable Ultrasound Scanner (PC) With Low Price
Brand: carejoy
SKU: 136269545
Availability: InStock

US$ 1,400 - 2,999 MOQ: 1 Unit

Key Specifications

Type:

Portable Ultrasonic Diagnostic Devices

Brand Name:

carejoy

Model Number:

RUS-9000A

Beijing Carejoy Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing

Delivery Detail:

Delivery time depends on order quantity.

Type Portable Ultrasonic Diagnostic Devices

Brand Name carejoy

Model Number RUS-9000A

Place of Origin Beijing, China

Applicable fields

Suitable for the diagnosis of Abdomen, Cardiac, Gynecology, Obstetrics, Thyroid Gland, Small Organs, Urology and so on.
Widely used for clinical examination and diagnosis. They are the ideal equipments to meet the needs of various kinds of hospitals and clinics.

Leading Digital Technologies

DBF: Digital Beam Forming
RDA: Real-time dynamic aperture imaging
DRA: Dynamic real-time acoustic apodizer
DRF: Dynamic receiving focus
DFS: Dynamic frequency scanning, frequency range: 2.0-12.0MHz, 4 kinds of scaning frequencies

Advantages:

Embedded PC platform is adopted in the ultrasonic master system
THI
DFC Dynamic frequency scanning
Histogram, Sectionl drawing, Puncture guide
Save hundreds of thousands of images and cine loop permanently
Dynamic real-time PIP local zoom functions
Double connectors
Double USB ports
Multiple kinds of OB. measurement reports, fetus physiological grades and reports and fetus growth curve
Auto-create report systems of Gyn., small organs, cardiac, urology and other sections
Compatible of jet printer, laser printer, video printer and video recorder

Image Processing:

Display mode: B, 2B, 4B, B/M, M
Image precess technologies: controllable frame correlation, Gamma correction, edge enhancement, image smoothing, image denoisiong, automatical gain adjustment, up/down, left/right and black/white conversation
Dynamic Range: 100Db, 4 steps of switches
Image magnification, stepless magnification, dynamic real-time PIP local zoom functions
Cine loop: 256 frame auto/manual cine loop; multi screens cine loop (4B, 9B); auto/manual cine loop under B/M and M mode
Image management system: the functions of pigeonholing, browsing, comparing, saving, printing and transferring images; as many as hundreds of thousands of images and thousands of cine loop could be saved; saved images could be operated by full-screen browse under slide mode.

Software Functions:

Measurement and calculation: measure perimeter and area by distance or ellipse method; measure perimeter and area by track method; measure body surface area and volume by ellipse method. 4 measure sticks; rate measure; linear stenosis ratio, area stenosis ratio, angle measure. All calculations are automatic.
Assist tools: puncture guide, histogram, sectional drawing
Menu manage interface, real time online support and navigation clew system, image fore-set and one-key optimization functions
Auto-measure software of OB., Gyn., small organs, cardiac, urology and others:

OB.: BPD, CRL, GS, HA, AC, HC, FL, APAD, TAD, FTA, HUMERUS, OFD, THD, TIBIA, ULNA, FI, LIMP, BBT, FBP

Gyn.: uterus diameter, intima thickness, ovary colume, regnant ovarian follicle, length of cervix long-diameter, uterine

Small organs: thyroid gland, hip joint

Cardiac: AOD, LAD, IVSTd, LVIDd, AA, LAD/AOD, LVPWd, LVIDs, EF, EF SLP, CA/CE, MVCF, CO, CI, LVMWI, AVSV, FS, ACV, ET, SV, SI, LVMW, QMV

Urology: remained urine sample, prostate, PSAD

Presetting system for diagnosis and measurement formulas. Different formulas could be set according to different races.
Patient cases database systems. All the data could be saved, searched and managed
Multiple kinds of OB. measurement reports, fetus physiological grades and reports and fetus growth curve
Auto-create report systems of Gyn., small organs, cardiac, urology and other sections

Standard Configuration:

Main unit
10.4 inches SVGA high resolution non-interlaced monitor
256 frame auto/manual cine loop; multi screens cine loop (4B, 9B); auto/manual cine loop under B/M and M mode
Two probe connectors
Two USB ports
3.5MHz R60/R50 electronic convex transducer(2.0/5.0MHz, 96 elements)

Optional:

Relative extended ports:

VGA, S-Video, TV video port
USB2.0 port, 2G saving card
RJ-45 network port
Multiple kinds of saving modes are all supported, containing soft disk, hard disk, falsh disk, CF card, SD card and others.
Compatible of jet printer, laser printer, video printer and video recorder
