Help CenterDigital 12-channel Touch Screen Color Electrocardiograph ECG EKG Machine With Low Price
Related Products
-
Standard 10 Leads Patient Cable Digital 12 Channel Electrocardiograph ECG Machine EKG-1212A Touch ScreenNegotiableMOQ: 1 Set -
2016 Best Sale Portable Medical 12-channel Electrocardiograph ECG Machine EKG Machine EKG-1212A-ShellyUS$ 100 - 1,000MOQ: 1 Set
-
EKG-1212A Portable 12 Channel 10 Inch TFT LCD Touch Screen Digital Electrocardiograph ECG MachineNegotiableMOQ: 1 Set
-
CE Portable 12 Channel ECG MachineUS$ 700 - 900MOQ: 1 Unit
-
CE &ISO13485 Approved Digital 12-channel Touch Screen Color Electrocardiograph ECG EKG MachineNegotiableMOQ: 1 Set
Features:
- 12 channel digital ECG machine with interpretation
- Simultaneous acquisition of 12-lead ECG signal
- Manual/Auto/Arrhythmia analysis modes
- Real time ECG, 20 patients cases
- Alphabetic keyboard for patient info
- Multiple printing modes
- 320x240 graphic, 10 inch LCD
- High resolution thermal printing system
- High resolution digital filter
- Built-in USB or RS232, optional PC-ECG software
- AC/DC power, built-in rechargeable Ni-MH battery
- Light weight, portable, convenient for use
Specification:
Safety standard |
IEC60601-1 class I, type CF |
Lead |
Standard 12 Leads, Lead change automatically |
Resolution |
12 bit / 1000Hz |
Operation mode |
Manual/Auto/Analysis modes |
Filter |
AC, EMG filter |
Drift filter |
Anti-drift system |
Input circuit |
Floating; Protection against Defibrillator effect |
CMRR |
>100dB (with filter) |
Input circuit current |
<0.1μA |
Input impedance |
≥50ΜΩ |
Calibrating voltage |
1mV±3% |
Frequency response |
0.05Hz~160Hz (IEC) |
Time constant |
>3.2seconds |
Noise level |
≤15Vp-p |
Threshold |
≤20μV |
Sensitivity |
Auto 2.5, 5, 10, 20, 40mm/mV |
Recording system |
High resolution thermal printer |
Paper speed |
25, 50mm/s±3% |
Recording paper |
210/216mmx20m, roll/fold paper |
Power supply |
AC: 220V / 110V, 50/60Hz |
LCD display |
320x240 graphic, 5.7 inch LCD |
Dimensions |
285×265×72mm |
Weight |
3.8kg |
Send Inquiry to This Supplier
