Endoscopy 10W LED Cold Light Source CLS-650A compatible STORZ, WOLF, OLYMPUS supplier

LED Cold Light Source

DESCRIPTION

The unit built-in LED bulb, the high energy conservation, the multi-transformations, the favorable environmental protection, the long life cycle. It provides the colour temperature of approx. 9500 k corresponding to sunlight. The latest circuit technology provides optimum performance and functionality.

Compact and portable, the built-in lithium battery allows the CLS7515 work more than 2 hours after being recharged. We design and manufacture it for use either with a rigid or flexible endoscope. A particularly well conceived safety feature is the automatic switchover from main light source to the spare light source in case of light source failure. Therefore the light source is always ready for emergency use and contributes to patient safety.

TECHNICAL DATA

Power supply: AC110/220V±10%,50/60HZ
Battery: Lithium battery
Bulb: OSRAM LED bulb, approx.3 to 10 W
Safety standard: IEC601-1
Color temp.:approx.9,500 K
Illumination: ≥140,000 Lx
Life cycle of bulb:  approx.1,200 h
Storage temp.: -15°C to +50°C
Operating temp.: 0°C to 45°C
Relative humidity:30% to 90%
Device type: I/B
Light of flexible :φ27mm, L:145mm.
N.W.: 0.25 kg
Light of rigid endoscope :φ24mm, L:115mm.
N.W.: 0.2 kg
Connection: STORZ, WOLF(optional), OLYMPUS etc.

* According to the test setup by the manufacturer, service life may be shorter when used under unfavorable conditions (e.g .many ON/OFF cycles)
