CE*ISO Certified Resting 12 Lead Signal 7 Inch 6 Channel Digital Electrocardiograph ECG Machine Monitor EKG 1206A
US$ 450 - 750
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Visual Acuity Examination Apparatus
Brand Name:
Carejoy
Place of Origin:
Beijing, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cheap Price 3 Channel Resting ECG Machine Electrocardiograph Electrocardiogram EKG FactoryUS$ 280 - 450MOQ: 1 Set -
7 Inch Portable Resting 3 Channel 12-lead Electrocardiograph ECG Machine EKG-903A3 With CE ISO ApprovedUS$ 280 - 450MOQ: 1 Set
-
Mini Sync Software Electrocardiograph ECG Machine EKG-80A2 1 Channel 12 LeadUS$ 280 - 360MOQ: 1 Set
-
New Arrival .Portable / Handheld Color Screen ECG EKG Heart Monitor PC-80B Model -MaggieUS$ 110 - 190MOQ: 1 Set
-
Portable Easy ECG EKG Handheld Heart Rate Monitor Sensor PRINCE 180D -MaggieUS$ 200 - 300MOQ: 1 Set
Type
Visual Acuity Examination Apparatus
Brand Name
Carejoy
Place of Origin
Beijing, China
Model Number
EKG-1206A
Carejoy CE certified Resting 12-lead signal 7 inch 6 Channel Digital Electrocardiograph ECG Machine EKG-1206A new model
Product Description
Features:
- Six channel digital ECG machine with interpretation
- Simultaneous acquisition of 12-lead ECG signal
- Manual/Auto/Arrhythmia analysis modes
- Real time ECG, 20 patients cases
- Multiple printing modes
- 112mm 3/6-ch format recording
- 320x240 graphic, 7 inch Color LCD
- High resolution thermal printing system
- High resolution digital filter
- Built-in USB or RS232, optional PC-ECG software
- AC/DC power, built-in rechargeable Ni-MH battery
- Light weight with handle, convenient for use
Specification:
Safety standard |
IEC60601-1 class I, type CF |
Lead |
Standard 12 Leads, Lead change automatically |
Resolution |
12 bit / 1000Hz |
Operation mode |
Manual/Auto/Analysis modes |
Filter |
AC, EMG filter |
Drift filter |
Anti-drift system |
Input circuit |
Floating; Protection against Defibrillator effect |
CMRR |
>100dB (with filter) |
Input circuit current |
<0.1μA |
Input impedance |
≥50ΜΩ |
Calibrating voltage |
1mV±3% |
Frequency response |
0.05Hz~160Hz (IEC) |
Time constant |
>3.2seconds |
Noise level |
≤15Vp-p |
Threshold |
≤20μV |
Sensitivity |
Auto 2.5, 5, 10, 20, 40mm/mV |
Recording system |
High resolution thermal printer |
Paper speed |
25, 50mm/s±3% |
Recording paper |
112mmx20m, roll/fold paper |
Power supply |
AC: 110v-220V, 50/60Hz DC: 14.4V rechargeable NI-Ion battery (2200mAh) |
LCD display |
320x240 graphic, 7 inch LCD |
Dimensions |
285×265×72mm |
Weight |
3.5kg |
Click the link for more styles:
https://jxkh.en.china.cn/productgrouplist-801123345/ECG.html
Contact Information
Company Information
Our Services
1. 18 months warranty for the mainframe from date of shipment under normal use and service.
2. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the equipment, and after-sale maintenance and more.
3. Carejoy Medical provides free technical & service training to the technical & sales staff of distributors for the related products and will further provide technical assistance via e-mail, Skype as requested by the distributors. The training will be performed in Beijing China.
4. OEM/ODM services are available.
