Home > Health & Medicine > Medical Equipment > Medical Diagnosis Equipment > ISO13485 White Color Multi-function 12 Lead Resting PC Based ECG Monitoring System
ISO13485 White Color Multi-function 12 Lead Resting PC Based ECG Monitoring System
US$ 100 - 1,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Blood Testing Equipments
Brand Name:
OEM
Place of Origin:
Beijing, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CE ISO Approved 12-lead / 3 Channel Analysis System 72 Hours Recording Mini LCD Holter Monitor EcgUS$ 399 - 899MOQ: 1 Set -
CE ISO 12 Channel 12 Lead Color LCD Display Mini Holter ECG With 24 Hours RecorderUS$ 400 - 700MOQ: 1 Set
-
CE Approved High Grade 3-lead Color LCD Holter 24-hours Recorder System Ecg Holter Monitor With Software-CardioscopeUS$ 450 - 680MOQ: 1 Set
-
24 Hours ABPM Ambulatory Blood Pressure Monitor SpO2 DetectingUS$ 280 - 470MOQ: 1 Set
-
CE ISO Certified ABPM SpO2 Ambulatory Blood Pressure Monitor 24 Hours Recording Time With PC Software Free CuffUS$ 280 - 470MOQ: 1 Set
Type
Blood Testing Equipments
Brand Name
OEM
Place of Origin
Beijing, China
Model Number
PC-ECG
ISO13485 White color Multi-function 12 lead Resting PC based ECG Monitoring system
Product Description
Function (8 functions):
- ECG: 12-lead resting PC-ECG with auto interpretation
- VCG: Vector-cardiograph with auto interpretation
- TVCG: Timed Vector-cardiograph
- FCG: Frequency ECG (unique technique to detect ischemia and CAD)
- HFECG: High Frequency ECG
- SAECG(VLP): Signal Averaged ECG or Ventricular Late Potentials, time domain and 3-D frequency domain)
- QTD: QT Dispersion with chroma map
- HRV: Heart Rate Variability (time domain, 3-D frequency domain, Lorenz poincare plots
Hardware Features:
- High sampling rate of 1000Hz
- Digital filter system
- Applying anti-baseline-drift technology ensuring the stability of ECG baseline
- Wilson and Frank hookup system
- Meet the international standard of IEC60601-1
- Easy operation and perfect printout
- Diagnosis of coronary heart disease
- Perfect time domain, frequency domain and non-linear HRV analysis
- Perfect ECG database management system
Specification:
- Sample rate: 1000Hz, simultaneous 12 leads recording
- Resolution:12bit
- Power: 5.0V (DC)
- Patient Insulation: 4000V AC
- Defibrillation Protection: Built-in box
- Digital resolution: 2μV
- Frequency response: 0.05-250 Hz
- Common mode rejection: >90dB
- Input impedance: >10MΩ
- Time constant: ≥3.2 s
- Max electrode potential: ±300mV DC
- Dynamic range: ±10mV
- Isolate voltage: 4000V
- Current leak: <10μA
- Patient cable: standard 10-wire, 15-pin D connection
- PC interface: USB
Click the link for more styles:
https://img13.fr-trading.com/productgrouplist-802944204/PC_ECG.html
Hot Sale
Click the picture for detalied information:
Contact Information
Company Information
Our Services
1. 18 months warranty for the mainframe from date of shipment under normal use and service.
2. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the equipment, and after-sale maintenance and more.
3. Carejoy Medical provides free technical & service training to the technical & sales staff of distributors for the related products and will further provide technical assistance via e-mail, Skype as requested by the distributors. The training will be performed in Beijing China.
4. OEM/ODM services are available.
