Electro--optic Q--Switched Series

Specifications

Electro--optic Q--Switched series

Electro-optic Q Switched series working theory

Electro-optic Q---switched instrument means to add a polarizer and a KD*P crystal in the laser resonator.The light passes through the polarizer into linearly polarized light ,if the KD*P crystal add λ/4 voltage, due to the pockles effect ,make the trip through the crystal linearly polarized light vibration direction change of 1/2.If the KD*P crystal has not voltage ,back through the crystal linearly polarized light vibration direction unchanged .Thus ,when the crystals have voltage ,beam is not through resonant cavity ,and the resonant cavity at low Q state .Due to external excitation , the population will increase rapidly .When the voltage on the crystal suddenly removal ,the beam can be freely throght the resonant cavity , the resonant cavity at high Q value .There by it produced laser pulse .Electro--optic Q--switched fast ,can be in 10-8 seconds to complete a switch function ,the peak power of the laser reaches the gigawatt level .If the original resonant cavity laser is linearly polarized in the device , electro---optic Q---switched measures need not be placed polarizing plate.

Treatment range

It's mainly used for removing endogenous pigmented skin lesions ,exogenous pigment skin problems and traumatic pigmentation .

Endogenous pigmented skin lesions :nevus of ota,itou,mongolia spot ,zygomaticofacial nevus fuscoceruleus,coffeespots ,freckles,seborrheic keratosis,nevus,junctional nevus,melanosis,blue nevus,post inflammatroy pigmentation such as chloasma.1064QA pigment laser therapeutic instrument in large spot mode has higher energy density in due to train physicians how to use 1064QA treating post inflammatory pigmentation ,chloasma which has a good clinical effect.

Exogenous pigmented skin problems:tattoo,eyeliner,lip and traumatic tattoo and other pigmented skin lesions .Because 1064QA has a strong enough energy density which is more effective in the treatment of exogenous colored skin problems induced by mixed type pigment.

Main parameters

Laser types : electro-optic Q---switched ND:YAG laser

Wavelength :532nm,1064nm

Pulse energy :≤1000mj&1064nm ; ≤500mj&532nm

Pulse width: about 6ns

Spot diameter:1-7mmcontinuously adjustable

Work frequency :1--10HZ

Working voltage:AC 220V±10%   50HZ AC 110V±10%  60HZ
