The premium Q-switched Nd:YAG Laser offers the light of single wavelength 1064/532nm with sequential and uniform energy output, which will be on the target tissue directly to shatter pigments cell, not damage any normal tissue. It is very safe and effective treatment procedure for various tattoo and pigment lesions.
By bonding technology, the treatment performance is more effective than previous, it is our newest development with advantages of no light leakage, no need to debug, lower than 1‰ maintenance and much longer life time.
Newest tatoo/pigmentation removal, q-switched nd yag laserlongpulselaser
Long Pulse
Long pulse laser theory
One of long pulse laser hair removal beauty equipment, long pulse adjustable pulse width-Gentle-YAG 1064nm laser, which comprises laser device, collimating indicating device, optical system, laser power, control system, cooling system and mechanical system. The laser device with long pulse Nd+3:YAG laser, and the pump source for with the new wave - current type laser power be connected with the long pulse krypton lamp, the chopper type-current type laser power be connected with control system CPU. CPU control the laser output power, pulse width and pulse waveform. Laser hair removal used a laser theory of selective photothermolysis. Melanin is the target color on follicles. After the laser irradiation, the melanin absorb energy, the energy is absorbed and converted to destroy follicles tissue thermal energy, to rise temperature rapidly. Hair lost the ability to regenerate and hair removal. Thick black hair is ideal for removal hair, not well for blonde,gray and white hair. However, only follicles on growth hair period hair contain abundant melanin, the strongest laser absorption, so laser work for hair on growth period. Moreover, each treatment only destroyed a part of follicles, which determines the laser hair removal to achieve satisfactory results by multiple treatments.
Gentle-YAG (1064nm) laser belongs to the near infrared light, the wavelength long, deep tissue penetration, 10mm depth, effectively destroy follicles.
Color 8 inch TFT LCD control system
Features
1.To be effective on all types of skin,most suitable for dark brown skin people;
2.It owns very strong penetrability,the powerful energy could arrive and effect on hair follicle;
3.With sapphire epidermis strong cooling system built in laser treatment handle,this could greatly ensure the safety during operation;
4.Adjustable long pusle width from 10ms-30ms,which could balance the energyintensity,greatly protect the normal skin in treatment.
Applications
Permanent hair removal on all skin types
Skin Rejuvenation
Skin Tightening
Wrinkles
Vascular
Facial Veins
Leg Veins
Clinical Principle Diagram
Technical Parameters
| Display Screen | 8.4 Inch True color Touch screen |
| Laser type | Nd:Yag long pulse laser |
| Wavelength | 1064nm |
| Spot size | 5mm,8 mm |
| Pulse width | 1-30ms |
| Pulse delay | 1-100ms |
| Energy density | 10-150J / cm2 |
| Pulses Repetition rate | 0.5Hz, 1Hz, 2Hz |
| Pulse mode | a number of synchronization |
Remove spot and nevus
The speed of flashes could be set 3Hz/5Hz.Keep 3-4 fingers distance between head of handle and treatment area. It is better to use high energy for treatment until treatment area seeps a little blood. It is advised to use 1064 nm head for normal spot and nevus treatment, but for deep color spot and nevus, it is better to use 532nm head for treatment. It should have a 15-30days interval to continue next treatment until remove all.
Package
Aluminum alloy case
Trade terms
1. Payment: T/T 100% in advance (Western Union or PAYPAL are welcomed)
2. Production lead time: 10-50 units: 5-10 days, 50~100 units:10-15 days, above 100 units: 15-20 days.
3. Sample can be delivered in 3 days
4. Shipping freight are quoted under your requests
5. Shipping port: Tianjin, Mainland China
6. Discounts are offered based on order quantities
7. MOQ:1 unit
Our service
1.Your inquiry related to our products or prices will be replied in 24 hrs.
2.Well-trained and experienced staffs to answer all your inquires in fluent English
3.OEM&ODM, any your customized products we can help you to design.
4.Distributorship are offered for your unique design and some our current models
5.Protection of your sales area, ideas of design and all your private informa
certificate
TREATMENT THEORY
Q-switched nd yag laser radiates the light ia absorbed by the pigmentations and results in an instantaneous blast that is light blasting principle The pigmentation particles are shattered into fragments some can be bounced out of the skin and others can be splited into tiny particles that can be engulfed by phagocytes and then eliminated by the lyphatic system.
