Help Center800mj High Quality Gentle No-Invasive Device Laser Hair Vascular Tumours Treatment Removal 1064nm Nd Yag Long Pulse Laser
Related Products
-
Q Switch Laser Machine Long Pulse Nd Yag Laser For Hair Removal And Vascular Removal Beauty Equipment Naevus Of Ota RemovalUS$ 1 - 1MOQ: 1 Set -
Facial Veins Treatment Keyword Laser Hair Removal Machine Price Nd Yag Laser Equipment Alma Laser Nd Yag Laser MachineUS$ 1 - 1MOQ: 1 Set
-
800mj 1064nm Medical ND YAG Long Mongolian Spots Removal Pulse Laser Hair Removal Machine PriceUS$ 1 - 1MOQ: 1 Set
-
Naevus Of Ito Removal Crystal Hair Treatment High Technology Long Pulse Q Switched ND: Yag Laser Hair Removal Machines World Best Selling Products 1-10HzUS$ 1 - 1MOQ: 1 Set
-
Q Switch Laser Tattoo Removal DIscounted Price Long Pulse Laser Machine With Tattoo Removal Laser Equipment ND-YAG For Hair And Toenail Fungus TreatUS$ 1 - 5,700MOQ: 1 Set
Remove spot and nevus
The speed of flashes could be set 3Hz/5Hz.Keep 3-4 fingers distance between head of handle and treatment area. It is better to use high energy for treatment until treatment area seeps a little blood. It is advised to use 1064 nm head for normal spot and nevus treatment, but for deep color spot and nevus, it is better to use 532nm head for treatment. It should have a 15-30days interval to continue next treatment until remove all.
High Quality Gentle No-Invasive Device laserlongpulseLaser
Q Switch ND YAG Laser
1.Products introduction
1064QA pigment laser therapeutic instrument using electro-optic Q-Switched mode, pulse width only 6ns, 1064nm laser single pulse energy up to 1000mj, instantaneous emission high laser energy efficient crush ill lesion group, namely, laser light induced blasting: laser accumulated high energy transient emission, wavelength 1064&532nm laser in a very short period of time ( 6ns ) instant action on target tissues, accordingly base absorbed light energy heating speed expansion and instantaneous blasting fragmentation, a part ( epidermis) base after fragmentation epidermal metabolism, one part ( epidermis following tissue ) color base after fragmentation can be macrophage phagocytosis particles, which digested by macrophages and excreted finally through the lymphatic circulation. Lesions base will be gradually reduced until it disappeared, while the surrounding normal tissues is almost no damage and has little clinical negative role because they do not absorb or minimal absorption wavelength 1064&532nm laser. Postoperative you need not to rest. Since electro-optic Q-switched laser energy is real continuous adjustable, the doctor obtains free energy density and spot size under a certain condition arbitrary energy density.
2.Treatment range
- It's mainly used for removing endogenous pigmented skin lesions, exogenous pigment skin problems and traumatic pigmentation.
- Endogenous pigmented skin lesions: nevus of Ota, Itou, Mongolia spot, zygomaticofacial naevus fuscoceruleus, coffee spots, freckles, seborrheic keratosis, nevus, junctional nevus, melanosis, blue nevus, post inflammatory pigmentation, such as chloasma. 1064QA pigment laser therapeutic instrument in large spot mode has higher energy density in due to train physicians how to use 1064QA treating post inflammatory pigmentation, chloasma which has a good clinical effect.
- Exogenous pigmented skin problems: tattoo, eyeliner, lip and traumatic tattoo and other pigmented skin lesions. Because 1064QA has a strong enough energy density which is more effective in the treatment of exogenous colored skin problems induced by mixed type pigment
3.Treatment principle diagram
4.Configuration characteristics
- 1064QA using electro-optic Q-switched method, as continuously adjustable single pulse energy, can provide a continuous adjustable energy value, to meet the various needs of physicians on the treatment. Even under the condition of certain spot diameter, doctors still can obtain appropriate energy density, which can not be achieved by any passive Q-switched equipment.
- 1064QA using light guide arm to transmit energy, so doctors feel more comfortable and avoid arouse a feeling of fatigue by therapeutic hand, while guaranteeing the treatment precision;
- 1064QA light guide arm end output 1064nm laser energy for 50---1000mj can adjust 25---500mj 532nm laser energy;
- Equipped with facular adjuster can obtain more stable, a variety of spot size physicians need ed;
- It sales several times than similar equipment on market to equip with special Heiwawa treatment head effect ;
- It's more effective choice to physician to treat chloasma and post inflammatory pigmentation ;
- The machine is high maintenance cost, inconvenient transportation and Q-switch device position offset easily leads in patients with burns
TREATMENT THEORY
Q-switched nd yag laser radiates the light ia absorbed by the pigmentations and results in an instantaneous blast that is light blasting principle The pigmentation particles are shattered into fragments some can be bounced out of the skin and others can be splited into tiny particles that can be engulfed by phagocytes and then eliminated by the lyphatic system.
5. Main parameters
The premium Q-switched Nd:YAG Laser offers the light of single wavelength 1064/532nm with sequential and uniform energy output, which will be on the target tissue directly to shatter pigments cell, not damage any normal tissue. It is very safe and effective treatment procedure for various tattoo and pigment lesions.
By bonding technology, the treatment performance is more effective than previous, it is our newest development with advantages of no light leakage, no need to debug, lower than 1‰ maintenance and much longer life time.
| Laser types | electro-optic Q-Switched ND:YAG laser |
| Wavelength | 532nm, 1064nm |
| Pulse energy | ≤1000mj&&1064nm;≤500mj&&532nm |
| Pulse width | about 6ns |
| Spot diameter | 1-7mm continuously adjustable |
| Work frequency | 1-10HZ |
| Working voltage | AC 220V±10%,50Hz AC 110V±10%,60Hz |
6.Curative effect contrast
7.Package
aluminum alloy case
8.shipping way
9.certificate
Function:
1.Getting rid of tatoos ,eyebrow,Ota's nevus .
2. Acne treatment
3.Skin rejuvenation
4.Pigmentation treatment
5.Vascular treatment.
6.Eliminate and smooth wrinkles treatment
7.Professional tatoo removal machine for sale
8.Body Tattoo & Eyebrow Tattoo & Eyeliner Removal
9.Various Pigmentation Lesions such as Freckles, Sun Spots,
10.Color Spots, Age Spots, Nevus, Birthmarks
11.Deep Facial Cleansing & Rejuvenation Assisted With Carbon Cream
