The premium Q-switched Nd:YAG Laser offers the light of single wavelength 1064/532nm with sequential and uniform energy output, which will be on the target tissue directly to shatter pigments cell, not damage any normal tissue. It is very safe and effective treatment procedure for various tattoo and pigment lesions.
By bonding technology, the treatment performance is more effective than previous, it is our newest development with advantages of no light leakage, no need to debug, lower than 1‰ maintenance and much longer life time.
New product in 2016 Q switched EO active nd :yag laser excimer laser tatoo removal machine in China
Treatment principle:
The Q-switched ND YAG laser takes specific wavelengths light in high energy, which are absorbed by the pigment and shatters the pigment into particles, breaking them into very small fragments , some parts will consequently bounce out of the skin and the other parts will spilt even further into minute particles; which eventually will be engulfed by the phagocytes and ultimately gets eliminated by the lymphatic system.
Application:
Pigment deposit dispelling
Color tattoo removal
Eliminates the age pigment, spot, birthmark
Pigment changes
Skin rejuvenation
Specifications:
Laser type |
Q-switch Nd Yag Laser |
Wavelength |
Single wavelength 1064nm, 532nm,1320nm Black doll |
Controller |
10.4” TFT true color touch LCD |
Single-pulse Energy |
1200mJ (1064nm); 400mJ (532nm) |
Power |
2000W |
Width of pulses |
6-12ns |
Frequency |
1-15 |
Diameter of spot |
1-7mm adjustable |
Working environment |
5-40°C |
Indicator of aiming light |
red semiconductor aiming light, wavelength 650-670nm, canbe turn off |
Cooling manner |
closed-off water circulation + air |
Dimension of machine |
83*32*83 cm |
Dimension of package |
100*54*100 cm |
N.W. |
60kg |
G.W. |
102.5kg |
Packing |
wooden case |
Voltage |
220V / 110V |
Advantages:
1. Electro-optic Q-switch Nd Yag Laser, releases actual single pulse of laser energy. Really achieve to painless treatment and micro-injury to skin, long-term lasting treatment result
2. Single pulse energy 800mJ
3. Professional for skin rejuvenation
Machine Features:
1. Spot size: 1-7mm adjustable
2. Excellent 7 articular-arm, to ensure the accuracy of long treatment and easy the operator’s hand greatly
3. Alarm protection system of water flow and water temperature: protect people and machine against any risk at the first time.
Product pictures
Before and After
Therapeutic range:
1.1064nm Wavelength:Remove black and dark bluetattoo pigments, such as tattoos, eyebrows, dark color around the eyes,
freckle, age spot etc.
2.532nm Wavelength: Remove red and brown tattoos and red mark.
3.1320nm wavelength:The 1320nm wavelength: Skin whitening and tightening.
Advantages:
Q-switched ND: YAG laser with dual wavelengths (1064nm&532nm).
8ns Pulse Width for ideal results on pigmentation and tattoo removal with reduced pain.
High terminal output energy (up to 1500mj) for more efficient results.
Repetition Rate is up to 6Hz for faster treatment.
Long-life designed laser system.
Multi-spot size 1-7mm is ideal for a wide variety of treatment parameters.
Spot size adjustor is optional.
