Specifications
1.Electro-optically Q-switch laser2. It's for medical clinic /hospital
3.Energy:800mj1064nm&400mj 532nm
Electro-optically Q-switch Laser ZF1
Treatment principle
Q-switch ND:YAG laser radiates specific wavelengths light in high peak energy pulse, and in ultra-short nano-second the light penetrates the specific tissue and is absorbed by pigment ,then result in an instantaneous blast.
The pigment particles shattered into fragments, parts of them will be expelled from skin, and the rest tiny particles
will be engulfed by phagocytes and then eliminated by lymphatic system.Best for epidermal and dermal pigment
lesion treatment;
|
Sphere of Application
|
1. Epidermal and dermal pigment lesion treatment; 2. Tattoo removal, remove all kinds of tattoo. 3. Pigment lesions: Sunspot, nevus of ota, Ito's nevus, Mongolian spot, age-pigment, Nevus , speckle, chloasma, birthmark etc. 4. Skin rejuvenation, tighten pore, improve oily face, whiten skin. |
|
|
Special features
|
1. The energy of single pulse can get to 800mj. it is easy and complete to remove the endogenous pigment 2. Computer system can control output power exactly which is more stability, without any risk. 3. It has good effect on more application including pigments on skin and dermis, lift the skin style and so on. 4. Humandesign interface, 10.4`inch color touch screen. Don’t need to change the heads. 5. Luxurious design and good working stability , designed for top medical institute and beauty salon ; 6. Adopt joint arm, can extend and shorten freely, fully meet different treatment area; 7. Strong cooling system makes excellent working stability, ensure 24 hours continuous working time; can marvelously meet longer treatment time; |
|
|
Technical Parameter |
Type of Laser |
Electro-optically Q-switch Laser |
Wavelength |
dual 1064nm and 532nm |
|
Pulse Width |
2.5ns |
|
Pulse Energy |
single 800mj |
|
Spot Diameter |
1-8mm |
|
Work Frequency |
1-10Hz adjustable |
|
Power |
1000W |
|
Voltage |
AC220V±10% 50Hz (AC110V±10% 60Hz) |
|
Dimension |
930mm*470mm*1120mm |
|
Certificate: Medical CE and ISO 13485
