Help CenterPortable Q-Switched Nd: YAG 1-10Hz Laser Pigment Removal Equipment Laser Tattoo Removal Equipment
Related Products
-
Permanent Tattoo Removal Nd Yag Laser Tattoo Removal Laser Equipment Tattoo Removal Machine Q Switched Nd Yag Laser Tattoo Removal MachineUS$ 800 - 1,500MOQ: 1 Unit -
Mongolian Spots Removal Vertical Q Switched Nd Yag Laser Tattoo Removal Q Switched Nd Yag Laser Tattoo Removal MachineUS$ 2,000 - 3,000MOQ: 1 Unit
-
Pigment Removal Tattoo Removal Age Pigment Birthmark Feature and Stationary Style nd Yag LaserUS$ 500 - 3,000MOQ: 1 Unit
-
Vertical ND YAG Q-Switch Laser Tattoo Removal Machine 1064nm 532nm 2 HandpiecesUS$ 500 - 3,000MOQ: 1 Unit
-
1064nm 532nm Q-Switch and Stationary Style Nd Yag Laser Tattoo RemovalUS$ 500 - 3,000MOQ: 1 Unit
1.Will not destroy hair follicle, will not injure ordinary skin
2.Suitable to all kinds of skin color people
3.Easy and fast treatment, no down time
4.Different housing with different color can make the style of machine matches the style of your hospital, clinic and salon.
5.Water temperature and water flow alarm system, keep machine from unexpected damage.
6.German import laser yellow rod ensure the lifetime of the handle, the rod make light transmittance higher and treatment effect better.
portable Q-Switched Nd: YAG Laser pigment removal equipment
Application of portable Q-Switched Nd: YAG Laser pigment removal equipment
1. Theory
The Q-Switched Nd: YAG Laser radiates specific wavelengths light in high peak energy pulse. The light penetrates skin and it is absorbed by pigment in ultra-short nanosecond (6ns) and results in an instantaneous blast. The pigment particles are shattered into fragments; parts of them will be bounced out of the skin and the other parts will be split into tiny particles that can be engulfed by phagocytes and then eliminated by lymphatic system.
2. The range of treatment
a. Remove soak lip, tattoo, lip line, age pigment, birthmark, etc
b. Dispel the coloring matter, dermatosis and the mixed pigment
c. Dispel the coloring matter aggradations,
d. Remove red, black, purple pigment line-eyebrow
3. wavelength
a.1064nm: remove black, grey, blue pigment. (other colors similar to black).
b.532nm: remove red pigment. (other colors similar to red)
specification of portable Q-Switched Nd: YAG Laser pigment removal equipment
|
Working Principle: Laser emitted by the system has a strong penetration ability which allows it to reach the deep layer of dermis. The pigment particles absorb the light energy and explode sharply, burst into the tiny pieces, thus diminish the color density and get rid of it. So the appliance can effectively do away with mutant pigmentations and vascular tissue based on undamaged ambient tissue. This is called ‘Selective heat absorption’ principle in medical field. |
|
Wavelength |
1064 nm and 532 nm |
Number of Treatment head |
one |
Pulse Duration |
6-10ns |
Energy density |
800 mj & 400mj |
Pulse rate |
1/2/3/4/5/6 Hz |
Cooling system |
water cooling, air cooling, semiconductor cooling |
Power supply |
220V/50Hz or 110V/60Hz |
Dimension(cm) |
14″×14″×10″(36cm×35cm×27cm) |
Net Weight |
16 kg |
Feature:
1. The latest hi-tech of laser explosion in twinkling.
2. Don’t break the hair follicle, or hurt the normal skin, or produce the scar formation.
3. Little sense of pain, anesthesia is unnecessary.
4. Short curing time and easy operation.
5. The high quality controlled solid-state laser complying with international standard of production.
6. Computerized with big LCD and show in double languages,English and Chinese.
5. advantage
a. The water tank is bigger than others, so our device can have a better effect of water circulation.
b. The (diameter) of our laser YAG bar is 5 mm.
c. Our machine can work for about 30 minutes, longer working time than others.
d. You will find that the capacitor we use is bigger than others, so our laser can make sure the power energy to reach 800mj & 400mj.
e. As one of the biggest Nd: Yag Laser Machine manufacturers in China, our company offers competitive price and excellent quality.
f. The shell is made of ABS environmental material and beautiful design.
g. Free training is offered both on our company and on line.
1.Eyebrow removal
