Working Theory:
Applying the technology of IPL and Bipolar Radio Frequency, the system acts on the entire corium layer, epidermal layer and subcutaneous tissue. On one hand, IPL destroys pathological pigments by photothermolysis effect, and stimulates the collagen and elastic fiber and gets the effect of tightening and whitening, on the other hand, biopolar RF release about 10 MHZ radio wave, high frequency vibration makes the skin molecule creating heat energy by friction, when the temperature reaches 68℃-72℃,the collagens extend will reproduce and recombine, enhance getting the effect of tightening skin and removing wrinkles.
Specifications
1.Three handles, Two IPL handles, one ND YAG handle
Hair tattoo removal skin rejuvenation Elight+IPL+RF with 3 in 1 Medical device
This model of Multifunction IPL and YAG laser system combines IPL and Q-switch ND: YAG laser function. IPL hair removal and skin rejuvenation system is based on IPL (Intense Pulsed Light) super photon technology. The IPL system emits a broad spectrum of intense pulsed light through the professional hand-piece. High quality crystal filters light in useless wavelength range. The light penetrates the tissue and is absorbed by either the blood when treating vascular lesions or the melanin when treating pigmented lesions or for hair removal and then damaging them. The body's natural processes then remove the injured tissue giving the skin a more even and youthful appearance.
The Q-switch laser unit can be working as laser tattoo removal and pigment removal. The pigmentation of body can be effectively broken up into pieces and removed by laser instantaneous high energy. Laser at certain wavelength can penetrate epidermis to lesion tissues within the extremely short time, then break up the corresponding chromospheres immediately. The corresponding pigment expands rapidly and explodes into pieces. Part of the pigment will be bounced out from patient’s body at the moment, while the other part the pigment will split into the tiny granules that can be engulfed by phagocytes of the body. After the digestion of phagocytes, it can be excluded from the lymphatic system. The pigment of the injured tissues gradually becomes shallow until disappears, while no injured trace will be left on the peripheral normal tissues, for they will not absorb the laser of the fixed wavelength.
Features
l Multi handpieces for different purpose: IPL hair removing, IPL rejuvenation, Laser tattoo removing.
l Integrated control panel for IPL and Q-switch nd:YAG laser.
l Exchangeable laser aimer supports 1064nm and 532nm wavelength output.
l Colorful touch screen control panel.
l High quality sapphire cooling coupling system.
l Enhanced circuit design for anti-jamming, which makes it be able to work stably.
l Optional big spot size output window to improve the treatment efficiency of IPL hair removal.
specification
Light Source |
Intense Pulse Light by Xenon flashlight Q-switch ND:YAG Laser |
IPL Spectra wavelength |
530 ~ 1200nm for Skin Rejuvenation 640 ~ 1200nm for Hair Removal |
IPL Spot Size |
8mm x 40mm |
Number of IPL Pulse |
1 ~ 6 adjustable |
IPL Energy Density |
0 ~ 50J/cm2, stepping at 1 J/cm2 |
IPL Spot Temperature |
0oC ~ -2oC |
IPL Pulse Duration |
0.1 ~ 100ms adjustable |
IPL Frequency |
1 ~ 3 Hz |
IPL Pulse Interval Delay |
0.1 ~ 100 Our Services 1.We will guarantee the quality of our equipment, all the beauty machines will have over 48 hours test, then the QC department check again the stability before packing. 2.If there is a deficiency, please leave message or call us, our technical department will check the machinesituation face to face on internet or you take some videos to show the situation. We will give reply and solve method within 24 hours. |
Laser wavelength |
1064nm and 532nm |
Laser Energy |
1064nm: < 1000mJ (multi-pulses) 532nm: < 500mJ (multi-pulses) |
Laser Pulse Width |
< 10nm |
Laser Frequency |
1~ 5 Hz |
Cooling System |
Air & Industrial level Built-in water cycle & Semiconductor cooling system |
Operation Interface |
Colorful touch screen control panel |
Power Supply |
220V/50Hz OR 110V/60Hz |
Power |
2200W |
Treatment Principle
Precipulse IPL Therapy System follows selective photothermolysis principle.Certain wavelength that can be used in and absorbed by targeted tissues.Targeted tissues will be destroyed according to targeted chromophore's selective absorption to light.What's more,the pulse width shall be smarller than or equal to targeted tissues' thermal relaxation time,then its damage to surrounding tissues will be minimized because of insufficient time for heat delivery.
Our Advantages
1. Specialized in production of medical and aesthetic equipments for many years.
2. The professional and innovative engineers are the pioneers of optoelectronics
in China.
3. ISO9001 proved Quality control and test system, each machine is in the best
quality control.
4. CE proved machines, the key for you to legally use and sell the machine.
5. Spare parts self produced, production cost is in control.
6.We provide 1 years warranty and 2 years, the few ones in China to supply 2 years warranty.
Our Service
OEM&ODM Services are available.
After Sale Service:
-Lifetime with professional engineer support.
-Within 1 year, supply spare parts for free if the machine has manufacturer quality problem
Any questions, pls feel free to contact me. Thanks!
Skype:sales6(at)
Contact person: wendy fan
IPL SHR Machine advantages:
1. The pulse energy keep stable, not fade away
2. Icons combined with letters on the screen, more easy for understanding and operating
3. Two fans equiped on the sides for better heat dissipation
4. Inner the back of machine, the lines are neat, the consumables keep on the outside, for easy replacement
