The range of IPL treatment:
(1)Everlasting hair removal:remove unwanted hairs under arms,on legs ,lips or other body part,etc.
(2)Pigmentation treatment:remove various kinds of pigment such as freckle,chloasma,aged spots,sunburn,etc.
(3)Telangiectasis treatment:treat angiotelec-tasis.
(4)Acne treatment:papule,tuber,Blain,acne,etc.
(5)Shrink pores,tighten skin,improve skin elasticity and glossiness.
(6)Eliminate and smooth wrinkles,acne treatment.
Principle of RF CO2 Fractional Laser
CO2 Fractional Laser System fires a laser beam which is split into numbers of microscopic beams, producing tiny dot or fractional treatment zones within the selected target area only. Therefore, the heat of laser only passes deeply through the fractional damaged area. This allows the skin to heal much faster than if the whole area was treated. During the skin self-resurfacing, a great amount of collagen is produced for skin rejuvenation, eventually the skin will look much healthier and younger.
Main Technical Parameters:
Laser wavelength: 10.6µm
Laser unit:TEM00 module Co2 unit (best quality for the facula)
Output power: super pulse output 0.3-7W, peak value 450W,continuous output 0.3-25W
Laser output mode: continuous, single pulse, repeat pulse, super pulse, with the optional pixel laser handpiece for Pixel laser output mode
Conducting system: seven joints longer articulated arm(the most advanced conducting light system in the world and the only one in China). It could be operated in the scope of R=1.7m, which makes the operation more flexible
Handpiece:multiple function handpiece and two kinds of focus lens for f=100mm and f=50mm. With the optional adapter, it could be used for orthopedic, gynaecology and ENT surgery
Operation mode:controlled by a touch screen and with the engineer interface and the doctor interface
Min. spot diameter:≤0.1mm, variable spot adjusting handpiece:0.1-2.5mm
Pulse width: the minimum pulse width is 0.1ms
Specifications
1.Scar removal
2.Skin renewing
3.Skin care
CO2 Fractional Laser
radio frequency (rf) fractional co2 laser equipment Main specifications:
Laser Type |
CO2 |
Wavelength |
10600nm |
Beam Delivery |
7-joint arm |
MaximumOutput Power: |
15W/30W/40W |
Optical Beam Quality |
TEM |
Spot Size |
0.12-1.25mm (Adjustable) |
Power of the Aiming Beam |
<5mW |
Aiming Beam |
635nm |
Scanning Mode |
Randomized Scanning |
Laser Operating Mode |
UltraPulse, CW, Fractional |
Cooling |
Air Cooling |
Pulse Energy |
10mj~200mj (every stepping:2mj) |
Spot Pattern |
Triangle/Square/Rectangle/Rhombus |
Pulse Interval |
1ms~100ms (every stepping:1mj) |
Scan Area |
10mmx10mm,20mmx20mm,30mmx30mm |
Working Mode |
Continuous operation |
Spot Density |
36 spots/cm,144 spots/cm,576spots/cm,with intermittent loading |
Power Supply |
AC 220V 50Hz/AC 110V 60Hz |
Net Weight |
45KGS |
|
Gross Weight The RF equipment has the cooling system of surface layer, and uses proprietary technology to deliver radiofrequency energy to the deep layers of the skin and its underlying tissue. The heat will accelerate the blood circle, lets the fibre structure shrink instantaneously, and stimulates the renewal of collagen. In response, the collagen shrinks and remodels over time, providing you with tighter skin, renewed facial contours. |
60KGS |
Dimensions (after packaged) |
760mmx455mmx975mm |
Product show
radio frequency (rf) fractional co2 laser equipment
Certificate
2. Provide free replacement parts and service warranty period free shipping
radio frequency (rf) fractional co2 laser equipment
1.Scar removal
2.Skin renewing
3.Skin care
4.Skin rejuvenation
5.CE, Medical CE, ISO13485, ISO9001
6.OEM manufacturer
7.Warranty
CO2 Fractional Laser
1. Skin renewing and resurfacing
2. Smooth burnt scars and surgery scars, etc
3. Wrinkle removal, skin tightening
4. Acne and acne scar removal
5. Remove intractable chloasmas and pigmentation
6. Sun damage recovery
fractional co2 laser for scar removal
1. Particular designed intelligent laser control system ensures a precise treatment
2. Laser energy shooting is an even steady and safe treatment process.
3. Wide range application, effective treatment
4. Easy and fast treatment, no down time.
Package
Treatment theory
e-light beauty equipment CE beauty machine combines three advanced technologies:Bipolar Radio Frequency + IPL + Skin Contact Cooling
The working theory is heating the dermis to a target temperature gradually,at that target temperature, it damages the hair follicles and prevents re-growth effectively,meanwhile avoiding injury to the surrunding tissue.A high repetition rate of single pulses are delivered deep into the dermis,achieving high average power and therappeutically effectively heat bulit-up,without the risk of injury and no pain virtually.
Shipping
Beijing Goldenlaser Development Co., Ltd.is a high-tech company which has been engaged in R&D, production, sale & after-sales service of beauty equipment and accessories since 2000. Presently, we have many high qualified engineers and a well-educated sales team. We communicate with many foreign Optical Engineering Research Centers to enlarge our scale and
increase investment in new products to meet the requirements of different markets. Our main business focuses on developing
and producing high quality beauty equipment inner accessories.
We are in the leading position in the field of beauty equipment.
We have independently developed Elight, diode laser hair removal, co2 fractional laser,ipl+diode laser,and all kinds of slimming
machine skin care products. With high technology, stable quality and perfect treatment results, these devices have won great
popularity among clients from all over the world. Furthermore, the best quality products make our company have great competitiveness
in the market, promoting technology of beauty to a high speed development level.
Our company insists on the "Quality is our life, integrity will win market" principle. With excellent product quality, we have won the trust
of our customers. We will make those who take great enthusiasm with Beauty friends' dream come true! Creating and maintaining a
leading position in world science and technology in Beauty field is the unshaken goal of Goldenlaser!
Application:
1. Application Range of Fractional treatment handpiece
a. Large pores, Fine lines, Skin tightening and whitening, Skin loosen(Deep Wrinkles), Stretch marks.
b. Various Scars: Burn Scars, Acne Scars, Surgical Scars and Keloid;
c. Reconstruction of photoaging skin.
2. Application Range of Incision Handpiece
a. Via multiple handles it can be adapted to Gynecology, ENT, Neurology and general surgery
b. In cosmetic surgery, it can be adapted to incisions for Blephaplasty, Skin Tags and Ingrow Nails, Compound Nevus and Intra Dermal Nevus etc
Fuctions and treatment effect of elight ipl rf
1.Permanent hair removal.
2.Smooth wrinkles, face-lifting
3.Deep flecks, epidermis flecks or pigment treating the telangiectasis
4.Promote collagen to grow, strengthen flexibility of skin
5.Acne treatment
6.Shrink the thick pore
7.For endogenous pigment: nevus of Ota, coffee spot, age pigment, freckle etc removal
8.For exogenous pigment: tattoo, eyeliner and eyebrow removal
9.Skin whitening
10.Striae gravidarum removal
