Help CenterAcne Scar Removal Co2 Fractional Laser For Ultra Spot Scar Pigment Removal Pulse Co2 Tube Laser Cutting Machine Skin Renewing
Related Products
-
Professional Co2 Fractional Laser For Vagina Cleaning Portable Co2 Laser Surgical EquipmentUS$ 10,000 - 15,000MOQ: 1 Piece -
Co2 Fractional Laser for High Voltage Co2 Laser Power SupplyUS$ 10,000 - 15,000MOQ: 1 Piece
-
Co2 Fractional Laser for 60w Co2 Laser Power SupplyUS$ 10,000 - 15,000MOQ: 1 Piece
-
Co2 Fractional Laser for Desktop Co2 Laser Engraver Mt3050dUS$ 10,000 - 15,000MOQ: 1 Piece
-
Co2 Fractional Laser for Co2 Laser Focus Lens HeadUS$ 10,000 - 15,000MOQ: 1 Piece
Features:
1. Different operation model choices.
2. Fast treatment without down time.
3. Automatic alarm system for operation and troubles
4. Small, compact and easy to use.
Specifications
2 fractional laser
co2 fractional laser for co2 fractional laser for co2 tube laser cutting machine
1.Product parameters:
Laser Type |
co2 fractional laser |
Wavelength |
10600nm |
|
Beam Delivery Features & Advantages: 1) Unparalleled char-free ablation, vaporization, excision, or incision of soft tissues . 2) Reduced thermal damage to surrounding tissues 3) Rapid healing and minimal downtime 4) Stimulate deeper collagen with high pulse energy 5) Adjustable scanning patterns and size. 6) Adjustable intensity of pilot beam from zero to maximum 7) Adjustable pulse duration 8) Last treatment setting memorization 9) Automatic alarm system for operation and troubles 10) Covers all functions of conventional system 11) No consumable costs. 12) High Energy Outputs, high effective |
7-joint arm |
Maximum Output Power |
35W/25W/15W (optional) |
Optical Beam Quality |
TEM |
Spot Size |
0.12-1.25mm (Adjustable) |
Power of the Aiming Beam |
<5mW |
Aiming Beam 635nm |
635nm |
Scanning Mode |
Randomized Scanning |
Laser Operating Mode l |
UltraPulse, CW, Fractiona |
Cooling |
Air Cooling |
Pulse Energy |
10mj~200mj (every stepping:2mj) |
Spot Pattern |
Triangle/Square/Rectangle/Rhombus |
Pulse Interval |
1ms~100ms (every stepping:1mj) |
Scan Area |
10mmx10mm,20mmx20mm,30mmx30mm |
Working Mode |
Continuous operation |
|
Spot Density
|
36 spots/cm² , 144 spots/cm², 576spots/cm² with intermittent loading |
Power Supply |
AC 220V 50Hz/AC 110V 60Hz |
Gross Weight |
88KGS |
Dimensions(before packaged) |
650mmx340mmx760mm |
Dimensions (after packaged) |
760mmx455mmx975mm |
2.Treatment Theory
Fractional laser light penetrates the skin with tiny thermal channels through the random scanning, creating an ablative and thermal effecton only channels (a micro-injury) without damaging the surrounding tissue. The tissue surrounding the micro-injury sites (about 15-20% of the treatment area) starts the process of healing. As collagen remodels, skin tightened, scars improved and pigmented lesions removed.
3.Application
(1). Application Range of Fractional treatment handpiece
a. Large pores, Fine lines, Skin tightening and whitening, Skin loosen(Deep Wrinkles), Stretch marks.
b. Various Scars: Burn Scars, Acne Scars, Surgical Scars and Keloid;
c. Reconstruction of photoaging skin.
(2). Application Range of Incision Handpiece
a. Via multiple handles it can be adapted to Gynecology, ENT, Neurology and general surgery
b. In cosmetic surgery, it can be adapted to incisions for Blephaplasty, Skin Tags and Ingrow Nails, Compound Nevus and Intra Dermal Nevus etc
4.GLO16 Advantages
(1)Three modes of laser energy output are selective: UltraPulse, CW and Fractional modes
(2)Adopt COHERENT RF-excited laser system enables the output quality more stable, more uniform, more consistent, (compared to ordinary CO2 laser installed with glass tubes)
(3)lHealing zone volume is adjustable, namely the volume of spots is adjustable in a certain healing zone. Therapists could adjust the spot density upon skin type, lesion parts and effectiveness requirement of different patients
(4)l Various spot volumes are suitable for different area of the body which maximally avoid the side-effect that result from the overlap of the spot, reduce the pain during the treatment, satisfy different therapiests' unique request.
(5)12.1" TFT touch LCD, rotated 360° gives you a luxury enjoyment;
(6)Reserved entry access for laser room ensures a safe treatment
(7)Comparing with existing traditional CO2 Sealed Glass Laser, RF excited CO2 lasts nearly permanently, therefore it deserves a higher initial cost which will be offset by a much lower total of ownership.
Working principle of fractional CO2 laser and vaginal tightening laser
1. skin resurfacing fractional CO2 laser
Fractional ablative CO2 resurfacing delivers 10600nm laser in fractional manner into the skin while leaving the untreated surrounding areas intact. Laser creates microscopic thermal dot on surface and performs within tissues, offering improve skin tightening, age spots, fine lines, acne scars, stretch marks removal and vulva rejuvenation. The untreated tissue helps to accelerate the healing process and rejuvenate the skin by promoting micro-circulation and new cell genesis.
2. vaginal tightening fractional CO2 laser
Fractional CO2 laser 10600nm is a very mature technology in the market. It creates microscopic thermal dots on the skin. These dots serves to enhance vaginal muscle tone, strength, and elasticity, while the intact skin helps these thermal dots recover.
It has an automatically 360° rotation articulate arm probe. It emits laser energy at a controlled depth inside the vaginal mucosa and achieve the functions of tighten vaginal, improve vaginal dryness, etc.
RF Fractional Co2 Laser Machine/co2 laser tube 60w/fractional co2 medical laser RF Fractional Co2 Laser Machine/co2 laser tube 60w/fractional co2 medical laser
3. Multi-functionl fractional CO2 laser for vaginal tighening and skin resurfacing
It's a more economic machine with both vaginal tightening and skin resurfacing function.
