Er Glass Fractional Laser Machine (Medical CE Approval)

Er Glass Fractional Laser Machine (Medical CE Approval) thumbnail-1
Er Glass Fractional Laser Machine (Medical CE Approval) photo-1
US$ 1 - 13,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Laser Type:
Other, erbium laser, erbium Laser
Q-Switch:
No
Style:
Portable
Contact Supplier Request Quote Chat Now
Beijing Goldenlaser Development Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
beijing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Laser Type Other, erbium laser, erbium Laser
Q-Switch No
Style Portable
Certification CE, ISO13485, ISO9000, ISO9001,SFDA, SGS, etc
Place of Origin Beijing, China
Brand Name GL
Model Number GL017

Specifications

Er glass fractional Laser machine (Medical CE approval)
1.with CE, ISO13485,ISO9001,ISO9000,etc
2. for skin whitening

Er glass fractional Laser machine (Medical CE approval)

1.with CE, ISO13485,ISO9001,ISO9000,etc
2. for skin whitening, skin renewing, skin care



Treatment Theory

The Er:bium Glass fractional laser skin reconstruction system adopts fiber laser with 1550nm wavelength and installs a CPG which is arranged in matrix scanning output, emitting 50um_80um spot through a high focusing lens, the target tissue is water in the dermis, forming matrix-like hole(0.12mm)around focal spot penetration directly. The penetration depth of these small spots is about 2mm (the depth is related with solar elastic fibrotic maximum depth). At this point the normal tissue among holes generates heat bridge which starts would rehabilitation reaction and thermal effects between scarfskin and dermal tissue, then experiencing inflammation phase, proliferation phase, remodeling phase. Drugs or cosmetic essence can be applied into the wound rehabilitation reaction, 1 hour after laser irradiation, the dermal fibrous tissue arranged dense, few inflammatory cells soakage, after 3days proliferation of epidermal cells, inflammatory cells of dermal layer is increased significantly, 15 days increasing in collagen synthesis, dermal thickening. After laser irradiation there is a certain effect for skin elasticity, skin hemoglobin content, water loss through the skin, sebum content, skin moisture content but no impact on the skin melanin content.



APPLICATIONS

1.  Patients with mild to moderate photoaging: Rough skin, large pores, fine wrinkles, skin loosen;

2.  Wrinkles caused by sunlight or early aging wrinkles, on the lower eyelid, forehead, cheek as well as crow’s-feet;

3.  Face lifting and tightening;

4.  Acne scar treatment



ADVANTAGES

I.The target tissue is water, no skin type limit (Fitzpatrick 1- VI);

IIThe output spot diameter is 50-80 um, less thermal ablation and deeper penetration, no scab, no pigmentation, no scar, more safe and effective treatment;

III.Random scanning avoids thermal damage caused by heat accumulation, reducing pain of treatment;

IV.Applied 1550nm fiber laser from IPG, the maximum output power is 35W which is 2-3 times of similar equipment, ensuring a deep penetration and long life time;

V.Six scan patterns(Circle/Triangle/Square/Rectangle/Rhombus/line) are available via CPG for different parts of skin, satisfying different therapists’ unique request;

VI.Laser output spot size, energy density, scan pattern, scanning speed, spot density, scanning area are adjustable, which were controlled by the computer operating system for various lesions, the tissue can be gasified at different depths (50-2000um), to ensure a more accurate treatment;

VII.The GLO17 can be equipped with different laser power of 15W, 25W and 35W. The doctors can choose the most appropriate laser power according to treatment



SPECIFICATIONS

Beam Delivery :    Fiber

Wavelength:       1550nm

Optical Beam Quality:   TEM

Maximum Output Power:  35W/25W/15W (optional)

Power of the Aiming Beam: <5mW

Spot Diameter:  50-80 µm

Aiming Beam:  635nm

Scanning Mode:  Randomized Scanning

Cooling:  Air Cooling

Pulse Energy:  10mj~200mj (every stepping:2mj)

Spot Pattern:  Triangle/Square/Rectangle/Rhombus

Pulse Interval:  1ms~100ms (every stepping:1mj)

Scan Area:  10mmx10mm,20mmx20mm,30mmx30mm

Working Mode: Continuous operation

Spot Density : 36 spots/cm² , 144 spots/cm², 576spots/cm² with intermittent loading

Power Supply:  AC 220V 50Hz/AC 110V 60Hz

Net Weight:   33KGS

Gross Weight:  76KGS

Dimensions (before packaged): 650mmx340mmx760mm

Dimensions (after packaged) :900mmx470mmx1000mm
