cheap price portable handheld ultrasound scanner
Functions
Cine loop: 365 frames bidirectional cine-loop
Storage media: Built-in flash, external pen drive
Storage: Min. 50 frames permanent storage and 16-frame snapshot
Body mark: 64 types
Probe auto-detection
10-level acoustic power output adjustment
Main parameter
General |
Imaging mode |
B, B+B, 4B, B+M, M |
Gray scales |
256 |
|
Display |
10 inches non-interlaced SVGA |
|
Probe connector |
2 standard |
|
Beam-forming |
Digital Beam-forming |
|
Scanning angle |
From 30 to 120 degree (depending on probes) |
|
Scanning depth (mm) |
From 40 to 250 (depending on probes) |
|
|
Imaging Processing
|
Pre-processing: |
Post-processing: |
|
Measurement & Calculation |
B-mode: Distance, circumference/perimeter, area, volume, angle, hip joint, stenosis ratio |
M-mode: Distance, time, velocity, EF slope, heart rate |
Software packages |
Abdomen, gynecology, obstetrics, urology, small parts, cardiology |
|
Standard Configuration
Main Unit
10" Non-interlaced SVGA
365 Frames Bi-directional Cine Loop
Min. 1600 Frames Permanent Storage
16 Frames Snapshot
Body Mark: 64 Types
Tissue Harmonic Imaging(THI)
Tissue Specific Imaging(TSI)
Professional Software Packages
2 Transducer Connectors
2 USB Ports
Optional
Electronic Micro-convex Array Transducer |
5.0/6.5/8.5MHz |
2.5/3.5/5.0MHz | |
6.5/7.5/9.0MHz | |
Electronic Convex Array Transducer |
2.5/3.5/5.0MHz |
Electronic Linear Array Transducer |
6.5/7.5/9.0/10.0MHz |
Electronic Endorectal Array Transducer |
5.0/6.5/7.5MHz |
Electronic Transvaginal Array Transducer |
5.0/6.5/7.5/9.0MHz |
5.0/6.5/7.5/8.0MHz | |
Video Printer | |
Laser Printer | |
Mobile Trolley | |
Flash Stick | |
Needle-guided Biopsy | |
Footswitch | |
product display
Warranty
One year free maintenance for this machine .
We guarantee quick and efficient service and maintenance of our device security solutions around the world. We ensure that we will be there whenever or wherever you need us, 24 hours a day, 365 days a year. Like all Onity solutions, our products are backed by a commitment to provide superior global service with local support. we can help you work and reach your goals.
