body scanning machine
Main parameter
General |
Imaging mode |
B, B+B, 4B, B+M, M |
Gray scales |
256 |
|
Display |
10 inches non-interlaced SVGA |
|
Probe connector |
2 standard |
|
Beam-forming |
Digital Beam-forming |
|
Scanning angle |
From 30 to 120 degree (depending on probes) |
|
Scanning depth (mm) |
From 40 to 250 (depending on probes) |
|
|
Imaging Processing
|
Pre-processing: |
Post-processing: |
|
Measurement & Calculation |
B-mode: Distance, circumference/perimeter, area, volume, angle, hip joint, stenosis ratio |
M-mode: Distance, time, velocity, EF slope, heart rate |
Software packages |
Abdomen, gynecology, obstetrics, urology, small parts, cardiology |
|
Optional
Electronic Micro-convex Array Transducer |
5.0/6.5/8.5MHz |
2.5/3.5/5.0MHz | |
6.5/7.5/9.0MHz | |
Electronic Convex Array Transducer |
2.5/3.5/5.0MHz |
Electronic Linear Array Transducer |
6.5/7.5/9.0/10.0MHz |
Electronic Endorectal Array Transducer |
5.0/6.5/7.5MHz |
Electronic Transvaginal Array Transducer |
5.0/6.5/7.5/9.0MHz |
5.0/6.5/7.5/8.0MHz | |
Video Printer | |
Laser Printer | |
Mobile Trolley | |
Flash Stick | |
Needle-guided Biopsy | |
Footswitch | |
Standard Configuration
Main Unit
1) 10" Non-interlaced SVGA
2) 365 Frames Bi-directional Cine Loop
3) Min. 1600 Frames Permanent Storage
4) 16 Frames Snapshot
5) Body Mark: 64 Types
6) Tissue Harmonic Imaging (THI)
7) Tissue Specific Imaging(TSI)
8) Professional Software Packages
9) 2 Transducer Connectors
10) 2 USB Ports
Functions
Cine loop: 365 frames bidirectional cine-loop
Storage media: Built-in flash, external pen drive
Storage: Min. 50 frames permanent storage and 16-frame snapshot
Body mark: 64 types
Probe auto-detection
10-level acoustic power output adjustment
Product display
Warranty
There are one year free maintenance for the host machine and more than one year life time.
We guarantee quick and efficient service and maintenance of our device security solutions around the world. We ensure that we will be there whenever or wherever you need us, 24 hours a day, 365 days a year. Like all Onity solutions, our products are backed by a commitment to provide superior global service with local support. we can help you work and reach your goals.
Packing&Shipping
All items are exported by carton case. Machine will be complete accommodating in it properly.
